TE Connectivity 1-1586585-4

mpn1-1586585-4
brandname: TE Connectivity
manufacturername: TE Connectivity

TE Connectivity Part Number 1-1586585-4

Brand: TE Connectivity
PartNumber: 1-1586585-4
Manufacturer: TE Connectivity
Label: TE Connectivity

Attributes

Key	Value
Application	Power
Applications	General Purpose, Indust.
Base Product Number	1586585
Body Orientation	Straight
Brand	TE Connectivity
Category	Connectors, Interconnec.
Color	Natural
Connector System	Wire to Board
Connector Terminates To	Printed Circuit Board
Connector Type	Header
Contact Finish	Tin Plated
Contact Finish - Mating	Tin
Contact Finish - Post	Tin
Contact Finish Thicknes.	39.4?in (1.00?m)
Contact Finish Thicknes.	39.4?in (1.00?m)
Contact Length - Mating	-
Contact Length - Post	0.138" (3.50mm)
Contact Material	Brass, Brass Alloy
Contact Plating	Tin
Contact Plating Thickne.	0.1 ?m
Contact Shape	Square
Contact Type	Male Pin, Pin
Current Rating	9A, 9 A
Current Rating (Amps)	9A
Description	CONN HEADER VERT 14POS .
Detailed Description	Connector Header Throug.
Digi-Key Part Number	1-1586585-4-ND
Fastening Type	Latch Holder
Features	Circuit Identification .
Flammability Rating	UL 94 V-2
Height	14.1 mm
Hole Center to Center	4.2 mm
Ingress Protection	-
Insulation Color	Natural
Insulation Height	0.555" (14.10mm)
Insulation Material	Polyamide (PA), Nylon
Item	Header
Length	36 mm
Manufacturer	TE Connectivity AMP Con.
Manufacturer Product Nu.	1-1586585-4
Manufacturer Standard L.	26 Weeks
Mated Stacking Heights	-
Material	Nylon
Material Flammability R.	UL94 V-2
Max. Insulation Dia.	3.1 mm
Max. Temp.	105?C
Max. Voltage	600V AC
Mfr	TE Connectivity AMP Con.
Mounting Type	Through Hole
Number Of Contacts	14
Number of Contacts	14
Number of Positions	14
Number of Positions Loa.	All
Number of Rows	2
Number Of Rows	2
Operating Temperature	-40?C ~ 105?C
Overall Contact Length	-
Package	Tray
Package Quantity	1
Pitch	4.2mm, 4.20 mm (0.165")
Pitch - Mating	0.165" (4.20mm)
Primary Type	Soft Shell
Product Status	Active
Row Spacing - Mating	0.165" (4.20mm)
Series	VAL-U-LOK Series, VAL-U.
Shrouded/Unshrouded	Shrouded
Shrouding	Shrouded - 4 Wall
Standards	CSA Certified; UL E2847.
Style	Board to Cable/Wire
Terminal Finish	Tin Plated
Terminal Type	Through Hole - Solder
Termination	Solder
Termination Method	Solder
Type	Vertical Header
Voltage Rating	600VAC
Width	0.59 in

All Prices

Seller	Supplier SKU	Min Price	MOQ	In Stock	Brand	Preferred Tier
us.rs-online.com	70041581	0.37	1	700	TE Connectivity	0.37 @ 350
Onlinecomponents.com	1-1586585-4	0.4399	1	700	TE Connectivity / AMP Brand	0.4181 @ 400
Waldom	TE CONNECTIVITY AMP BRAND 1-1586585-4	0.48	200	1300	TE CONNECTIVITY/AMP BRAND	0.48 @ 350
Future Electronics	2559573	0.576	100	350	TE Connectivity	0.576 @ 350
Digi-Key	1833584	0.670285714286	65	3290	TE Connectivity AMP Connectors	0.619168831169 @ 385
RS Delivers	865-3703	0.7356	100	350	TE Connectivity	0.7356 @ 350
Newark	95Y4828	0.818	1	1300	AMP - TE CONNECTIVITY	0.818 @ 350
Zoro	G700939140	152.0	1	350	Te Connectivity	152.0 @ 350
AmazonSC	B00DEEB4CC	251.41	1	350	TE Connectivity	251.41 @ 350
