INA PCFTR30

Ina PCFTR30 Ball Bearing Flange Unit

Ina PCFTR30 Ball Bearing Flange Unitzoom

Attributes

Key Value
Bearing Housing Materia.Cast Iron
Bearing Insert Material52100 Chrome Steel
Bearing Insert TypeBall
Bearing LubricationFAG Arcanol-MULTI2 or N.
Bearing Material Grade100Cr6
Bolt Circle Diameter116 mm
Bolt Hole Center-to-Cen.100.5 mm
Bolt SizeM10
Bolt Spacing4 Inch | 102 Millimeter
Bore1.181 Inch | 30 Millime.
Bore Dia.30 mm
Bore Diameter30 mm
Bore TypeCylindrical
Cartridge Pilot Depth0 Inch | 0 Millimeter
Cartridge Pilot Diameter0 Inch | 0 Millimeter
Category - BDIFlange Block
Center Height36 mm
ClosureDouble Sealed
Country of Origin (subj.Slovakia
Dimension A24 mm
Dimension D30 mm
Dimension H144 mm
Dimension H2117 mm
Dimension J116 mm
Dimension N11.5 mm
Dynamic Load Capacity19,500 N
EAN4012802791013
Expansion / Non-expansi.Non-expansion
FinishPainted
Flange Thickness12 mm
Harmonized Tariff Code8483.20.40.40
Housing Configuration1 Piece Solid
Housing MaterialCast Iron
Housing Material FinishPainted
Housing Style3 Bolt Triangular Flang.
Housing TypeTriangular
Inch - MetricMetric
Included BearingRadial Insert Ball
IncludesC3 Clearance, Grade 10 .
Insert Part NumberGRAE30NPPB
Item3 Bolt Flange Bearing
Keyword StringFlanged
Length Thru Bore1.409 Inch | 35.8 Milli.
Load DirectionRadial
Locking TypeEccentric Locking Collar
Long Description3 Bolt Triangular Flang.
Lubricant MaterialLithium Complex Grease
Lubrication OpeningsThreaded Lubrication Ho.
Manufacturer Item NumberPCFTR30
Manufacturer NameSCHAEFFLER GROUP
Maximum Temperature50 Degrees C
Minimum Buy QuantityN/A
Minimum Temperature-30 Degrees C
Mount Hole Size11.5 mm
Mounting Bolt SizeM10
Mounting Bolts11.5 Millimeter
Mounting MethodEccentric Collar
Nominal Bolt Circle Dia.4.6 Inch | 117 Millimet.
NounBearing
Number of Mount Holes3
Number of Mounting Holes3
Other FeaturesSingle Row | With Set S.
Overall Height117 mm
Overall Length117 mm
Overall Width40 mm
Pilot ConfigurationNo Pilot
Product Group - BDIM06110
RelubricatableYes
Rolling ElementBall Bearing
Rolling Element Rows1
Seal MaterialNitrile Rubber
SealsDouble Lip Contact
Self Lubricating BearingNo
SeriesPCFTR
Shaft Locking TypeEccentric Collar
Split HousingNot Split
StandardsGTB14 DIN1680-2
Static Load Capacity11,300 N
Static Radial Load Capa.11,300 N
System of MeasurementMetric
Temp. Range-20 Degrees to 120 Deg.
UNSPSC31171501
Weight / Kilogram1.186
Weight / LBS2.183

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomBDI Express117647989.8261474311INA2.609289.82614743 @ 1
thumbzoomZoroG011447397.01In Stock50Ina2.6297.0 @ 1
thumbzoomPurvisPCFTR30126.611In StockINA126.61 @ 1
