Lovejoy 24496 Size LF1 Torsional Coupling Cylinder, Inch, 0.31" Rough Stock Bore, 2.2" Outside Diameter, 1.44" Flange Diameter

Lovejoy 24496 Size LF1 Torsional Coupling Cylinder, Inch, 0.31" Rough Stock Bore, 2.2" Outside Diameter, 1.44" Flange Diameterzoom

Attributes

Key Value
Allowable Continuous Vi.44.00 in-lb
Bore TypeRough Stock Bore
ColorMetallic
Coupling SizeLF1
Coupling TypeTorsional
Cubic inches1.30886 in3
Description:LF1-HUB CYL-.31 RSB;
Dimension HD1.180 in (30.00 mm)
Dynamic Torsional Stiff.1240.00 in-lb/rad
Hub StyleCylindrical
Length thru Bore0.940 in (24.00 mm)
ManufacturerLOVEJOY INC
Max. Angular Misalignme.3.00 ?
Max. Bore (Dimensions I.0.63 in (19.00 mm)
Max. Parallel Misalignm.0.060 in (1.50 mm)
Max. Speed10000 rpm
Max. Torque200.00 in-lb
MFG Part #:68514424496
Min. Bore (Dimensions I.0.310 in (8.00 mm)
Nominal Torque90.00 in-lb
Normal Temperature Range-40 to 194 ?F
Rough Stock Bore Size0.310 in
Shore Hardness60A
Static Angular Stiffness2.66 in-lb/deg
Static Axial Stiffness220.00 lb/in
Static Radial Stiffness860.00 lb/in
Supplier:LOVEJOY INC
Thread (Dimension T)M6
UPC:685144244963
Weight0.26 lb
Wind-Up Angle at Max. T.17.00 ?
Wind-Up Angle at Nomina.6.00 ?

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomusmegastore.com6851442449670.681In StockLovejoy0.2670.68 @ 1
thumbzoomheavydutydepot.com6851442449670.682In StockLovejoy70.68 @ 2
cbtcompany.com6851442449681.471In StockLovejoy81.47 @ 1
kscdirect.comLOV 6851442449685.591In StockLOVEJOY INC85.59 @ 1
thumbzoommidwestapplianceparts.com68514424496-LJ-P113.061In StockLovejoy113.06 @ 1
thumbzoomRaptor SuppliesAK6ZWA117.93629251In StockLOVEJOY117.9362925 @ 1
Airline HydraulicsLOVEJOY 68514424496133.761In StockLOVEJOY133.76 @ 1
