Lovejoy 68514424497

B004QWZH9W

Lovejoy 24497 Size LF1 Torsional Coupling Model 2 Flanged Hub, Inch, 0.31" Rough Stock Bore, 2.2" Outside Diameter, 1.44" Flange Diameter

Lovejoy 24497 Size LF1 Torsional Coupling Model 2 Flanged Hub, Inch, 0.31" Rough Stock Bore, 2.2" Outside Diameter, 1.44" Flange Diameterzoom

Attributes

Key Value
Allowable Continuous Vi.44.00 in-lb
Bore TypeRough Stock Bore
ColorMetallic
Coupling SizeLF1
Cubic inches4.54960 in3
Description:LF1-HUB FLNG-.31 RSB;
Dimension FD1.440 in (36.58 mm)
Dimension FOD2.200 in
Dynamic Torsional Stiff.1240.00 in-lb/rad
Hub Diameter1.180 in (30.00 mm)
Length thru Bore0.940 in (24.00 mm)
ManufacturerLOVEJOY INC
Max. Angular Misalignme.3.00 ?
Max. Bore (Dimensions I.0.880 in (22.35 mm)
Max. Parallel Misalignm.0.060 in (1.50 mm)
Max. Speed10000 rpm
MFG Part #:68514424497
Min. Bore (Dimensions I.0.310 in (8.00 mm)
Nominal Torque90.00 in-lb
Operating Temperature R.-40 to 194 ?F
Rough Stock Bore Size0.310 in
Securing Torque for Mou.200.00 in-lb
Shore Hardness60A
Speed10000.00 rpm
Static Angular Stiffness2.66 in-lb/deg
Static Axial Stiffness220.00 lb/in
Static Radial Stiffness860.00 lb/in
StyleFlange
Supplier:LOVEJOY INC
Thread (Dimension T)M6
TypeTorsional
UPC:685144244970
Weight0.26 lb
Wind-Up Angle at Max. T.17.00 ?
Wind-Up Angle at Nomina.6.00 ?

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
AmazonSCB004QWZH9W51.01In StockLovejoy51.0 @ 1
thumbzoomusmegastore.com6851442449780.561In StockLovejoy0.2680.56 @ 1
thumbzoomheavydutydepot.com6851442449780.562In StockLovejoy80.56 @ 2
kscdirect.comLOV 6851442449799.181In StockLOVEJOY INC99.18 @ 1
thumbzoommidwestapplianceparts.com68514424497-LJ-P131.031In StockLovejoy131.03 @ 1
Airline HydraulicsLOVEJOY 68514424497155.021In StockLOVEJOY155.02 @ 1
