Leeson 171529.60

Leeson 300HP 1800RPM.449T.TEFC.460V.3PH.60HZ.CONT.40C.1.15S.F C-FACE.GENERAL PURPOSE (171529.60)zoom

Leeson 300HP 1800RPM.449T.TEFC.460V.3PH.60HZ.CONT.40C.1.15S.F C-FACE.GENERAL PURPOSE (171529.60)

B078XNX8SH

Attributes

Key Value
Amperage325.0 Amps
Amperage Rating325 A
Application TypeGeneral Purpose AC Motors
Bearing TypeBall
BearingsBall
Catalog Number171529.60
CategoryElectric Motor
CompositionCast Iron
Country of Origin (subject to change)China
Description:..300HP..1800RPM.449T.TEFC.460V.3PH.60HZ.CONT.40C.1.15S.F..RIGID.C449T17FB
Dimensions53.07 in L x 689 mm H
Drive End Bearing Size6319
Drive End Bearing TypeBall
DutyContinuous
Efficiency96.2
Efficiency %96.2 %
EnclosureTEFC, Totally Enclosed Fan Cooled
Enclosure TypeTotally Enclosed Fan Cooled
Family SeriesLeeson Motors
Frame447/449T, 449T, 447, 447T
Frame MaterialCast Iron
Frequency60, 50 Hz
Frequency Rating60/50 Hz
Gross Weight0 lbs
Horsepower300 hp
HP300
Hz60
Insulation ClassClass F, F
Item ConditionFACTORY NEW
Item Number171529.60
KW224.0
ManufacturerLEESON ELECTRIC CORPORATION, Leeson
Manufacturer Part Number171529.60
MaterialCast Iron
MFG Part #:171529.60
MountRigid Base Mount
mountingRigid Base
Mounting TypeFoot Mount, Rigid Base
NEMA Frame447/449T
Net Weight0 lbs
Nominal Voltage480 VAC
Number of Poles4
Number of Speeds1
Opp. Drive End Bearing Size6317
Opp. Drive End Bearing TypeBall
Phase3, 3 ph
Power300 hp
RotationReversible
RPM1788, 1,788 RPM, 1800
Service Factor1.15
Shaft3-3/8" dia. x 8-1/2" w/ 7/8" key
Shaft Diameter3.375
Shaft Length8.5
Shaft Size3-3/8 in Dia x 8-1/2 in L
Shpg.2653 lbs.
Size53.07" x 35.94" x 27.48"
Speed1788 RPM
Supplier:LEESON ELECTRIC CORPORATION
UPC:691720043752
Voltage460 AC, 460
Voltage (AC)460 VAC
Volts460

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomelectricmotorwholesale.com17152915411.01In StockLEESON2558.015411.0 @ 1
thumbzoomMRO Supply283433618970.521In StockLeeson18970.52 @ 1
thumbzoomapexindustrialautomation.com171529.6019700.151In StockLeeson19700.15 @ 1
thumbzoomDealers Electric171529.6024489.441In StockLeeson2593.024489.44 @ 1
thumbzoomGalco171529.60-LEES27222.031In StockLeeson27222.03 @ 1
thumbzoomsurpluscenter.com10-282430037.151In StockLeeson30037.15 @ 1
thumbzoomZoroG248557330076.11In Stock10Leeson30076.1 @ 1
kscdirect.comLEE 171529.6031952.761In StockLEESON ELECTRIC CORPORATION31952.76 @ 1
