- mpn0015247060
- brandname: Molex
- manufacturername: Molex
Molex Connector, Rcpt, 6Pos, 2Row, 4.2Mm - 15-24-7060
- Brand: Molex
- PartNumber: 15-24-7060
- PackageQuantity: 1
- Manufacturer: Molex
- Label: Molex
Attributes
| Key | Value |
|---|
| Alternate Mfr Part Numb. | 42385-06A1 |
| Angle | Straight |
| Applications | Polyamide (PA66), Nylon. |
| Base Product Number | 001524 |
| Category | Connectors, Interconnec. |
| Circuits (Loaded) | 6 |
| Circuits (maximum) | 6 |
| Color | Natural |
| Color - Resin | Natural |
| Connector Type | Receptacle, Female Sock. |
| Contact Finish - Mating | Tin, 100.0?in (2.54?m) |
| Contact Finish - Post | Tin, - |
| Contact Finish Thicknes. | 100.0?in (2.54?m), Natu. |
| Contact Finish Thicknes. | 2, 100.0?in (2.54?m) |
| Contact Length - Post | 0.138" (3.50mm), -40?C . |
| Contact Material | Brass, 100.0?in (2.54?m) |
| Contact Shape | Brass, Square |
| Contact Type | Female Socket, Board to. |
| CSA | LR19980 |
| Current - Maximum per C. | 9.0A |
| Current Rating | 9 A |
| Current Rating (Amps) | 600V, - |
| Description | CONN RCPT 6POS 0.165 TI. |
| Detailed Description | 6 Position Receptacle C. |
| Digi-Key Part Number | WM17601-ND |
| Durability (mating cycl. | 30 |
| Duration at Max. Proces. | 5 |
| Family Name | Mini-Fit BMI |
| Fastening Type | Tin, Push-Pull |
| Features | Blind Mating, Board Loc. |
| Flammability | 94V-2 |
| Guide to Mating Part | Yes |
| Ingress Protection | -, Board Lock |
| Insulation Color | Natural, 0.446" (11.33m. |
| Insulation Height | 0.138" (3.50mm), 0.446". |
| Insulation Material | Square, Polyamide (PA66. |
| Manufacturer | Molex |
| Manufacturer Product Nu. | 0015247060 |
| Manufacturer Standard L. | 17 Weeks |
| Mated Stacking Heights | - |
| Material - Metal | Brass |
| Material - Plating Mati. | Tin |
| Material Flammability R. | Tin, UL94 V-2 |
| Max. Cycles at Max. Pro. | 1 |
| Mfr | Molex |
| Mounting Type | Solder, Through Hole |
| Number of Circuits | 6 |
| Number of Contacts | 6 |
| Number of Positions | All, 6 |
| Number of Positions Loa. | All, 0.165" (4.20mm) |
| Number of Rows | 2 |
| Operating Temperature | UL94 V-2, -40?C ~ 105?C |
| Orientation | Vertical |
| Package | Tray, - |
| Part Status | Receptacle |
| PCB Locator | Yes |
| PCB Retention | Yes |
| PCB Thickness - Recomme. | 1.00mm |
| Pitch | 4.20 mm (0.165") |
| Pitch - Mating | 0.165" (4.20mm) |
| Pitch - Mating Interface | 4.20mm |
| Plating Material | Tin |
| Polarized to Mating Part | Yes |
| Primary Type | Soft Shell |
| Process Temperature max. | 240 |
| Product Status | Active |
| Row Spacing - Mating | Through Hole, 0.165" (4. |
| Series | Tray, Mini-Fit BMI 4238. |
| Special Features | Low-Halogen |
| Style | Board to Board or Cable. |
| Temperature Range - Ope. | -40? to +105?C |
| Termination | Solder, Push-Pull |
| Termination Interface: . | Through Hole |
| Type | Vertical Header |
| UL | E29179 |
| UPC Code | 800754209052 |
| Voltage - Maximum | 600V AC (RMS)/DC |
| Voltage Rating | 600V, General Purpose, . |
