- mpn15-910-30-PSI/KPA
- brandname: NOSHOK
- manufacturername: NOSHOK
NOSHOK 900 Series ABS Liquid Filled Dual Scale Dial Indicating Pressure Gauge with Back Mount, 1-1/2" Dial, +/-2.5% Accuracy, 0-30 psi Pressure Range
- Brand: NOSHOK
- PartNumber: 15-910-30-psi/kPa
- Model: 15-910-30-psi/kPa
- Size: 0-30 psi
- PackageQuantity: 1
- Binding: Misc.
- Manufacturer: NOSHOK, Inc.
- Label: NOSHOK, Inc.
Attributes
| Key | Value |
|---|
| Accuracy | 2.5, 2.5% |
| Ambient Temperature Ran. | -4 to 140?F, -4 to 140 |
| Ambient Temperature Ran. | -40 to 140?F, -40 to 140 |
| Application | AutomotiveConstructionH. |
| Basic Gauge Case Materi. | ABS |
| Case Material | ABS |
| Case Size | 1.5 " |
| Case Style | Center Back Mount |
| Case Type | Acrylonitrile Butadiene. |
| Category | 900 Series Acrylonitril. |
| Connection | 1/8 NPT |
| Connection Location | Back |
| Connection Material | Brass |
| Connection Size | 1/8, 1/8 in |
| Connection Type | NPT, National Pipe Thre. |
| Dial Size (In.) | 1-1/2 in |
| Dial/Display Size | Molded Plastic, White B. |
| Distribution Manifolds | NOSHOK`s Distribution M. |
| Family Series | NOSHOK Panel Meters & G. |
| Fill Liquid | 86.5/13.5 Glycerine H<s. |
| Filler Medium | Glycerine |
| Gauge Filled With | Glycerin/H2O |
| Gauge Lens Material | Acrylic |
| Gauge Primary Range Uni. | psi; kPa |
| Gauge Size | 1-1/2 |
| Gross Weight | 0 lbs |
| Inch/Metric | Inch |
| Item | Pressure Gauge |
| Item Number | 15-910-30-psi/kPa |
| Lens/Display Material | Acrylic; Ultrasonically. |
| Liquid Filled | Yes |
| Manufacturer | NOSHOK |
| Manufacturer Part Number | 15-910-30-psi/kPa |
| Material | ABS, Acrylonitrile Buta. |
| Maximum Value | 30 |
| Measuring Element | Copper Alloy C-Type Bou. |
| Media Temperature Range. | -4 to 140?F, -4 to 140 |
| Media Temperature Range. | -40 to 140?F, -40 to 140 |
| Minimum Value | 0 |
| Movement | Brass and Nylon with Hi. |
| Net Weight | 0 lbs |
| Note | Please consult your loc. |
| Package Quantity | 1 |
| Pointer | Molded Plastic |
| Pointer Material | Molded Plastic |
| Pressure Range | 0 to 30 psi, 0 to 30 |
| Price: | $54.25 |
| Product Series | 900 |
| Range | 0-30 psi |
| Related Items | 101-MFB, 100 Series 6,0. |
| Scale Option | psi/kPa Dual Scale |
| SchemaID | 101737 |
| Series | 900 |
| Syndication | 1 |
| Type | Pressure Gauge |
| Uninstalled Options and. | Certificate of Cleaning. |
| Unit | 1 |
| Units | Dual Scale: psi, kPa |
| Vacuum Measurement | No |
| Working Pressure Limita. | Dynamic PressureThe wor. |
