Fairchild Semiconductor TETTIP31C

B00Q6ZBS22

TIP31C Complementary Silicon Power Transistors 3A 100V TO220 Package 10 Pack

TIP31C Complementary Silicon Power Transistors 3A 100V TO220 Package 10 Packzoom

Attributes

Key Value
@Ic (test) (A)3.0
@VCE (V)4.0
CaseTO220
CategoryDiscrete Semiconductor .
Current - Collector (Ic.3 A
Current - Collector Cut.300?A
DC Current Gain (hFE) (.10 @ 3A, 4V
Derate Above 25?C16m
Forward Current Transfe.20
Frequency - Transition3MHz
Ic Max. (A)3.0
Icbo Max. @Vcb Max. (A)300u
ManufacturerFairchild Semiconductor
Max. hFE50
Max. Operating Junction.150 ?C
Max. PD (W)40
Maximum Collector Curre.3 A
Maximum Collector Power.40 W
Maximum Collector-Base .80 V
Maximum Collector-Emitt.40 V
Maximum Emitter-Base Vo.5 V
MfrFairchild Semiconductor
Min hFE10
Mounting TypeThrough Hole
Oper. Temp (?C) Max.150
Operating Temperature-65?C ~ 150?C (TJ)
PackageBulk
Package / CaseTO-220-3
Part StatusObsolete
Pinout Equivalence Numb.3-15
PolarityNPN
Power - Max2 W
Series-
SKU86702
Supplier Device PackageTO-220AB
Surface Mounted Yes/NoNO
Tr Max. (s)500n-
Transistor TypeNPN
Transition Frequency (f.3 MHz
TypeTransistor Silicon NPN
Vbr CBO80
Vbr CEO40
Vce Saturation (Max) @ .1.2V @ 375mA, 3A
Voltage - Collector Emi.40 V

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Digi-Key115130890.3120603015089953489Fairchild Semiconductor0.312060301508 @ 995
Rochester ElectronicsTIP310.372783489Fairchild Semiconductor0.37 @ 278
Little DiodeTIP315.9331285117Fairchild Semiconductor5.9331285 @ 10
thumbzoomAmazonB00Q6ZBS229.49110FAIRCHILD SEMICONDUCTOR9.49 @ 10
