CR Magnetics CR5210S-100

B005CWLOZQ

CR Magnetics CR5210S-100 Split Core DC Current Transducer with Single Element, >=2K Output Load, 24 VDC +/-10%, 0-100 ADC Input Range, +/-5 VDC Output Range

CR Magnetics CR5210S-100 Split Core DC Current Transducer with Single Element, >=2K Output Load, 24 VDC +/-10%, 0-100 ADC Input Range, +/-5 VDC Output Rangezoom

Attributes

Key Value
Accuracy?1%
Altitude2000 meter max
Basic Accuracy1.0 %
CategorySensors, Transducers
Cleaningwater-dampened cloth
Current - Sensing100A
Current - Supply (Max)35mA
For MeasuringDC
FrequencyDC
Frequency RangeDC Only
Installation CategoryCAT II
Insulation Voltage2500 VDC
Isolation Voltage3500KVRMS/1mA/1Sec
Linearity-, 10% to 100% FS
MfrCR Magnetics Inc.
Mounting TypeDIN Rail, Panel
MTBFGreater than 100 K hours
Number of Channels1
Operating Temperature0?C to +50?C, 0?C ~ 50?C
OutputRatiometric, Voltage
Output Load4-20 mADC - 0 to 500 ? .
PackageBulk
Package / CaseModule
PolarizationUnidirectional
Pollution Degree2
Product StatusActive
Relative Humidity5% to 95%, Non-Condensi.
Response Time250 ms, 250ms
Sensitivity-
Sensor TypeHall Effect, Closed Loop
SeriesCR5200
Supplier Device Package-
Supply CurrentTypical 30mA; Max 35mA
Supply Voltage24 VDC ?10%
Thermal Drift500 PPM/?C
Torque Specs3.0-inch lbs. (0.4Nm)
Vibration Tested ToIEC 60068-2-6,1995
Voltage - Supply24V
Weight0.5 lbs

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Digi-Key2500492254.791In Stock33CR Magnetics Inc.254.79 @ 1
thumbzoomprimebuy.comCR5210S-100283.21In StockCR Magnetics0.5283.2 @ 1
thumbzoomblackhawksupply.comCR5210S-100286.531In StockCR Magnetics286.53 @ 1
