ASHCROFT 35W1005PH02LVAC

mpn35W1005PH02LVAC
brandname: Ashcroft
manufacturername: Ashcroft

Vacuum Gauge, 30in Hg VAC to 0, 1/4inNPT

Brand: ASHCROFT
PartNumber: 35W1005PH02LVAC
Model: 35W1005PH02LVAC
PackageQuantity: 1
Manufacturer: ASHCROFT
Label: ASHCROFT

Attributes

Key	Value
Accuracy	+/-3-2-3%
Accuracy Grade	ASME B40.100 Grade B
Accuracy Scale	Mid-Scale
Ambient Operating Tempe.	-40 Degrees to 150 Deg.
Application	Beverage Dispensing Sys.
Basic Gauge Case Materi.	Plastic
Basic Gauge Sensor Mate.	Bronze
Basic Gauge Wetted Parts	Brass / Bronze
Blowout Safety Back	No
Brand	Ashcroft
Case Color	Black
Case Colour	Black
Case Depth	1.14 in
Case Diameter	3.7 in
Cleaned for Oxygen Serv.	No
Compatible Process Media	Water
Connection Size	1/4 in NPT
Current Stock	47
Dial Colour	White
Dial Face Material	Aluminum
Dry Dampening Feature	FlutterGuard
Field Fillable	No
Freeze Resistant Moveme.	No
Gauge Accuracy	+/-3-2-3%
Gauge Application	General-Purpose Case
Gauge Case Liquid	None
Gauge Case Material	ABS
Gauge Connection Locati.	Bottom
Gauge Connection Size	1/4 in
Gauge Connection Type	MNPT
Gauge Nominal Dial Size	3 1/2 in
Gauge Primary Range Num.	1
Gauge Primary Range Uni.	in Hg
Gauge Sensor Material	Bronze
Hazardous Location Rati.	Not Rated
Includes Calibration Ce.	No
Includes Mounting Hardw.	No
Includes Vent Plug	No
International Shipping	No
IP/NEMA Rating	Not Rated
Item	Industrial Vacuum Gauge
Lead Time	Expected to ship in 1-2.
Lens Material	Polycarbonate
Liquid Filled	No
Liquid-Filled Case	No
Manufacturer Warranty L.	1 yr
Manufacturers Warranty .	1 yr
Mounting Type	Stem-Mount
Movement Material	Polyester
Mpn	35W1005PH02LVAC
Nominal Dial Size	3 1/2 in
Non-Sparking	No
Panel-Mountable	No
Pointer Colour	Black
Pointer Material	Aluminum
Pressure and Vacuum Gau.	Vacuum Gauge
Pressure Gauge Type	General Purpose Dial Pr.
Pressure Range Type	Vacuum
Primary Pressure Range	30 to 0
Primary Pressure Scale .	Black
Primary Scale Minor Gra.	0.5
Primary Scale Numeric I.	1
Primary Scale Units	in Hg
Process Connection Gend.	Male
Process Connection Loca.	Bottom
Process Connection Size	1/4 in
Process Connection Type	NPT
Process Temperature Ran.	-40 Degrees to 150 Deg.
Range	30 in Hg Vac to 0
Removable Bezel	No
Scale Type	Single
Sensor Material	Bronze
Sensor Type	Bourdon Tube
Series	1005P
SKU	ZO-G8515981
Smallest Graduation	0.5 in Hg
Socket Material	Brass
Standards	ASME, CRN, UL 252A, UL .
SubCategory	Test Instruments
Vibration Resistance	Liquid-Filled

All Prices

Seller	Supplier SKU	Min Price	MOQ	In Stock	Brand	Weight	Preferred Tier
grainger.ca	WWG33HR30	14.02257192	1	In Stock	ASHCROFT	0.37	14.02257192 @ 1
Zoro	G8515981	15.35	1	86	Ashcroft	0.37	15.35 @ 1
simsupply.com	ZO-G8515981	23.24	1	47	Ashcroft		23.24 @ 1
sustainablesupply.com	C2757137	24.44	1	In Stock	Ashcroft	0.37	24.44 @ 1
Raptor Supplies	AH3QVF	36.135099	1	In Stock	ASHCROFT		36.135099 @ 1
