- mpn4JMW6
- brandname: Dayton
- manufacturername: Dayton
Pump, 1/3 HP, 115/230V, 6.8/3.4 Amp
- Brand: Dayton
- PartNumber: 4JMW6
- PackageQuantity: 1
- Binding: Misc.
- Manufacturer: DAYTON
- Label: DAYTON
Attributes
| Key | Value |
|---|
| Agency Compliance | CUS |
| Amps | 6.8/3.4 |
| Application | Liquids Transfer, Circu. |
| Bearing Type | Ball |
| Best Efficiency GPM @ H. | 10 gpm @ 26 ft, 10 gpm . |
| Best Efficiency Range G. | 11 to 19 gpm @ 28 to 6 . |
| Brand | Dayton |
| Cord Length | Not Applicable |
| Current Stock | 3 |
| Discharge Pipe Size | 1/2 in |
| Drain Plug | No |
| Duty | Continuous |
| GPM of Water @ 10 Ft. o. | 20 |
| GPM of Water @ 15 Ft. o. | 18 |
| GPM of Water @ 20 Ft. o. | 15 |
| GPM of Water @ 25 Ft. o. | 11 |
| GPM of Water @ 30 Ft. o. | 4 |
| GPM of Water @ 40 Ft. o. | 1 |
| GPM of Water @ 5 Ft. of. | In Stock |
| Height | 7 7/8 in, 7-7/8" |
| Housing Material | 304 Stainless Steel |
| HP | 1/3 hp, 1/3 |
| Hz | 60 |
| Impeller Material | 304 SS |
| Impeller Type | Closed |
| Includes | Manual |
| Inlet | 3/4" NPT, 3/4 in NPT |
| Inlet Pressure | 128 PSI |
| Intake Pipe Size | 3/4 in |
| International Shipping | No |
| Item | Centrifugal Pump, Chemi. |
| Length | 12-5/8", 12 5/8 in |
| Length (Straight Wirewa. | 12 5/8 in |
| Manufacturers Warranty . | 1 yr., 1 yr |
| Max. Case Pressure | 150 PSI |
| Max. Dia. Solids | 1/8", 1/8 in |
| Max. Fluid Viscosity | 31 SSU |
| Max. GPM @ Head | 21 gpm @ 5 ft., 21 gpm . |
| Max. Head | 48 ft., 48 ft |
| Max. Liquid Temp. | 200 Degrees F |
| Max. Specific Gravity | 1.0 |
| Min. GPM @ Head | 1 gpm @ 40 ft. |
| Motor Enclosure | TEFC |
| Motor RPM | 3,450 |
| Motor Type | PSC |
| Mpn | 4JMW6 |
| NEMA/IEC Frame | 56J |
| Outlet | 1/2" NPT, 1/2 in NPT |
| Overall Height | 7.9 in |
| Overall Length | 12.6 in |
| Overall Width | 9.3 in |
| Phase | 1 |
| Port Rotation | 90 Degrees Increments |
| Screw Material | Stainless Steel |
| Seal Material | Viton |
| Seal Type | Mechanical |
| Service Factor | 1.6 |
| Shaft Material | Stainless Steel |
| Shaft Outer Diameter | 7/16 in |
| SKU | ZO-G2688576 |
| Solid Diameter (Maximum) | 0.13 in |
| SubCategory | Pumps |
| UPC | 190735326701 |
| Voltage | 115/230 |
| Wetted Materials | Carbon, Ceramic, 304 St. |
| Width | 9-1/4", 9 1/4 in |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
 | Zoro | G2688576 | 580.58 | 1 | 10 | | Dayton | 28.57 | 580.58 @ 1 |
 | simsupply.com | ZO-G2688576 | 733.11 | 1 | 3 | | Dayton | | 733.11 @ 1 |
 | sustainablesupply.com | C1740253 | 741.28 | 1 | In Stock | | Dayton | 28.57 | 741.28 @ 1 |
| grainger.ca | GGM4JMW6 | 859.39785236 | 1 | In Stock | | DAYTON | 28.57 | 859.39785236 @ 1 |
 | Raptor Supplies | AD8EQW | 953.9822565 | 1 | In Stock | | DAYTON | | 953.9822565 @ 1 |
