MEAN WELL RPS-30-5

B0739G56JS

MW Mean Well RPS-30-5 5V 6A 30W Single Output Medical Type Power Supply

MW Mean Well RPS-30-5 5V 6A 30W Single Output Medical Type Power Supplyzoom

Attributes

Key Value
AC inrush currentCOLD START 40A/115VAC 8.
ApplicationsMedical
Approval AgencyCB, CE, cURus, TUV
ASINB0739G56JS
Base Product NumberRPS-30
CategoryPower Supplies - Extern.
ConfigurationOpen Frame
Current - Output 16 A
DescriptionAC/DC CONVERTER 5V 30W
Detailed DescriptionOpen Frame AC DC Conver.
Digi-Key Part Number1866-4042-ND
Dimension76.2*50.8*24MM
Dimension (LxWxH)127 x 76.2 x 41mm | 5 x.
Efficiency82%
EMC standardsEN55011/EN55022 class B.
FeaturesAdjustable Output, Univ.
Input Voltage80~264VAC
Is Discontinued By Manu.No
Item model numberRPS-30-5
Leakage currentEarth leakage current <.
ManufacturerMEAN WELL USA Inc.
Manufacturer Product Nu.RPS-30-5
Manufacturer Standard L.18 Weeks
MfrMEAN WELL USA Inc.
Minimum Load RequiredNo
Mounting TypeChassis Mount
Number of Outputs1
Operating Temperature-30?C ~ 70?C (With Dera.
Output Current6.6 A
Output Power33 W
Output Rated Current6A
Output Voltage5 VDC
Overload protection105%~135% hiccup mode, .
PackageTray
Power (Watts)30W
Primary TypeAC-DC
Product StatusActive
SeriesRPS-30 (30W), RPS-30 Se.
Setup, rise, hold up ti.1000ms, 30ms, 10ms at f.
Size / Dimension3.00" L x 2.00" W x 0.9.
TypeOpen Frame, Embedded
Voltage - Input80 ~ 264 VAC
Voltage - Isolation4 kV
Voltage - Output 15V
Voltage - Output 2-
Voltage - Output 3-
Voltage - Output 4-
Voltage - Output 6-
Wattage30
Withstand voltageI/P-O/P:4KVAC I/P-FG:2K.

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Onlinecomponents.comRPS-30-511.3110MEAN WELL11.3 @ 1
thumbzoompeaktopeakpower.comRPS-30-511.981In StockMean Well11.98 @ 1
thumbzoompowersupplymall.comRPS-30-514.69155Mean Well14.69 @ 1
thumbzoomNewark44AC727615.311In StockMEAN WELL15.31 @ 1
thumbzoomTMERPS-30-515.631In StockMEAN WELL15.63 @ 1
us.rs-online.com7087978117.95112MEAN WELL17.95 @ 1
RS Delivers103-466918.94812Mean Well18.948 @ 1
electricautomationnetwork.comRPS-30-518.961In StockMEANWELL18.96 @ 1
thumbzoomAmazonSCB0739G56JS19.051In StockMEAN WELL19.05 @ 1
thumbzoomDigi-Key770604919.5841In StockMEAN WELL USA Inc.19.584 @ 1
AmazonTPB01HTH80TY22.521In Stock5MEAN WELL22.52 @ 1
