Molex 171813-0003

B00LQPBKQG

Molex 171813-0003 Connector, Header, 3POS, 1ROW, 3.96MM

Molex 171813-0003 Connector, Header, 3POS, 1ROW, 3.96MMzoom

Attributes

Key Value
Alternate Mfr Part Numb.171813-0003
Alternate Part No.538-171813-0003
AngleVertical
ApplicationWire-to-Board
ApplicationsAutomotive, General Pur.
BrandMolex
ColorBlack
Connectorsocket
Connector pinout layout1x3
Connector seriesKK 396
Connector TypeHeader
Contact Finish - MatingTin
Contact Finish - PostTin
Contact Finish Thicknes.60.0?in (1.52?m)
Contact Finish Thicknes.60.0?in (1.52?m)
Contact GenderPin (Male)
Contact Length - Mating0.448" (11.38mm)
Contact Length - Post0.093" (2.35mm)
Contact MaterialBrass
Contact PlatingTin
Contact platingtinned
Contact ShapeSquare
Contact TypeMale Pin, Pin
Contacts pitch3.96mm
Current Rating7 A, 5 A
Current Rating (Amps)-
Electrical mountingTHT
Family NameKK 396
Fastening TypeFriction Lock
Features-
Flammability ratingUL94V-1
Flammability RatingUL 94 V-2
Housing MaterialNylon
Ingress Protection-
Insulation ColorBlack
Insulation Height0.446" (11.33mm)
Insulation MaterialPolyamide (PA), Nylon
Kind of connectormale
Latching TypeFriction Lock
Locking systemlatch
ManufacturerMolex
Manufacturer Part No.171813-0003
Mated Stacking Heights-
Material Flammability R.UL94 V-2
Mating Post Length11.38 mm
Max. operating voltage250V
Maximum current7A
MfrMolex
Mounting AngleVertical
Mounting TypeThrough Hole
Number of Circuits3
Number of Contacts3
Number of pins3
Number of Positions3
Number of Positions Loa.All
Number of Rows1
Operating Temperature-
Operating Temperature R.- 40 C to + 105 C
OrientationVertical
Overall Contact Length0.671" (17.05mm)
Package Quantity1
PackagingBulk
Part StatusActive
Pitch3.96 mm (0.156") In./mm.
Pitch - Mating0.156" (3.96mm)
Plating MaterialMatte Tin
Primary TypeBoard Mount
Product CategoryHeaders & Wire Housings
Product TypeHeaders
Row Spacing - Mating-
Series171813, 171813 Series
ShroudingShrouded - 1 Wall
Spatial orientationstraight
Special FeaturesLow-Halogen
StyleBoard to Board or Cable
TerminationSolder, Through Hole
Termination Post Length2.37 mm
Termination StyleThrough Hole
TradenameKK
TypeVertical Header, Shroud.
Type of connectorwire-board
Voltage Rating250 V, -

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
WaldomMOLEX 171813-00030.2412505833MOLEX0.241 @ 250
Avnet17181300030.24772007200Molex0.247 @ 7200
Onlinecomponents.com171813-00030.3181102697Molex0.318 @ 110
thumbzoomjensentools.com101526870.3213833Molex0.32 @ 1
us.rs-online.com703142870.433021230Molex Incorporated0.43302 @ 1
RS Delivers792-28530.62411740Molex0.624 @ 1
thumbzoomswatee.com171813-00030.831673Molex0.83 @ 1
thumbzoomTMEMX-171813-00031.1971139MOLEX1.197 @ 1
thumbzoomZoroG2748861120.01In StockMolex120.0 @ 1
