Burndy YA2CL45

B095RBZKS2

Burndy - YA2CL45 - 2STR CU 1-HO SHORT 45DEG - (Pack of 1)

Burndy - YA2CL45 - 2STR CU 1-HO SHORT 45DEG - (Pack of 1)zoom

Attributes

Key Value
ApprovalsCSA, UL
Certification - CSA App.Yes
Certification - cULusNo
Certification - UL Reco.No
Color CodeBrown
Color FamilyBrown
Conductor - Copper DLO .N/A
Conductor - Copper Str .60 (37) Navy
Conductor - Copper Str .60 (37) Navy
Conductor - Copper Str .2 AWG
Conductor - Copper Str .2 AWG
Conductor - MaterialCopper
Connector TypeTerminal
Country of OriginUS - United States
Country of Origin (subj.Unknown
Die ColorBrown
Die Index10
Dimension - B Length fr.7/8 in
Dimension - B Length in.0.88 in
Dimension - Bolt Hole S.0.33 in
Dimension - D inch0.70 in
Dimension - Height inch1.05 in
Dimension - Hole Size mm8 mm
Dimension - L Length Ov.41 mm
Dimension - Length Over.1.62 in
Dimension - N inch0.34 in
Dimension - Outside Dia.0.42 in
Dimension - Pad Width i.0.61 in
Dimension - Strip Lengt.15/16
Dimension - Stud Size i.5/16
Dimension - Z inch0.36 in
ECCNEAR99
Family SeriesBurndy Terminals
Feature - Barrel TypeStandard
FinishElectro Tin-Plated
Gross Weight0 lbs
Industry Standard(s)UL467
Item NumberYA2CL45
Lug Wire Size2 AWG
ManufacturerBurndy
Manufacturer Part NumberYA2CL45
MaterialCopper
Material/CompositionCopper
Max Conductor Range2 AWG
Min Conductor Range2 AWG
Net Weight0 lbs
Number of Holes1
Physical Attribute - Nu.1
Physical Attribute - To.45 Degree
Physical Attribute - To.Standard
PlatedY
Plating TypeTin - Electro Plated
Rating - KVA35 kV
Rating - Minimum Voltage600
Standards - RoHS Compli.CM
Stud Size5/16 in.
Trade NameHYLUG?
TypeStandard Barrel, Tin Pl.
UL ListedYes
UNSPSC39121432
Use WithCopper
Voltage - Maximum35000

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomusmegastore.comYA2CL4511.21In StockBurndy11.2 @ 1
Graybar9001331114.04481In StockBurndy14.0448 @ 1
thumbzoomGalcoYA2CL45-BURN16.4510In StockBurndy16.45 @ 10
thumbzoomZoroG067184316.5110In Stock35Burndy16.51 @ 10
