- mpnLE104M2-2
- brandname: Liberty Pumps
- manufacturername: Liberty Pumps
LIBERTY LE104M2-2
- Brand: Liberty
- PartNumber: LE104M2-2
- PackageQuantity: 1
- Binding: Misc.
- Manufacturer: Liberty
- Label: Liberty
Attributes
| Key | Value |
|---|
| ADA Compliant | No |
| Adjustable | No |
| AMP | 2.5 |
| Amperage Rating | 2.5 A Full Load/9.2 A L. |
| Application | Commercial, Residential |
| Automatic Shut-Off | No |
| Base Diameter | 12-1/2 in |
| Bearing Type | Ball |
| Brand | Liberty Pumps |
| Brand Model Compatibi. | LE-Series Sewage Pumps |
| Built-In Grinder | No |
| Category | Sewage Pumps |
| Clean Bagged | No |
| Coating | Epoxy, Powder Coated |
| Collection | LE100 Series |
| Color Finish | Black, Grey, Red |
| Color Finish Category | Reds |
| Cord Length | 25 ft |
| Cord Length in feet | 25 |
| Cord Type | SEOOW 25 ft |
| Corded Cordless | Corded |
| Country of Origin (subj. | United States |
| Cover Included | No |
| CSA Certified | CSA 22.2 No. 108 |
| Description: | 1 HP, Sewage Pump, 3 PH. |
| Diameter | 12-1/2 in |
| Dimensions | 12.5 in W x 18.9 in H |
| Discharge | 2 in |
| Discharge Configuration | Horizontal |
| Discharge Connection Ty. | FNPT |
| Discharge Size | 2 |
| End Connection 1 | FNPT |
| End Connections | FNPT |
| Energy Star Compliant | No |
| Fits Pipe Size | 2 in |
| Flow Rate | 109, 109 gpm |
| Frequency Rating | 60 Hz |
| GTIN | 671812101492 |
| Height | 21-1/2 in |
| Horse Power | 1 |
| Horsepower | 1 hp |
| Impeller | Two Vane Semi-Open |
| Impeller Type | Cast Iron 2-Vane Semi-O. |
| Installation Type | Freestanding |
| ISO Specifications | ISO 9001 |
| Item Weight (lbs) | 64 |
| Length | 15 in |
| MA Approved | Yes |
| Manufacturer | Liberty Pumps, Liberty . |
| Material | Cast Iron |
| Maximum Feet of Head | 36 |
| Maximum Head | 39 ft |
| Maximum Temperature | 104 |
| MFG Part #: | LE104M2-2 |
| Motor Speed | 1725 rpm |
| NSF Certified | No |
| Origin | Domestic |
| Outlet Size | 2 in Flanged |
| Overall Dimensions (L x. | 12.5 x 18.9 x 12.5 |
| Phase | 3, 3 ph, Three Phase |
| Power Source | Electric |
| Product Type | Pump |
| Pump Application | Sewage |
| Pump Body Material | Cast Iron |
| Pump Motor Type | Hermetically Sealed |
| Pump Mounting | Free Standing |
| Pump Phase | 3 |
| Pump Stage | 1 |
| RPM | 3450 |
| Series | LE100 |
| Service Factor | 1 |
| Supplier: | Liberty Pumps Inc |
| Switch | Manual |
| Temperature Rating | 104 |
| Type | Manual |
| UL Listed | UL 778 |
| UPC: | 671812101492 |
| VAC at 60 Hz | 480 |
| Voltage | 440-480 |
| Voltage Rating | 440 to 480 VAC |
| Volts | 440/480V |
| Weight | 64 |
| Width | 12 in |
