- mpnX210
- brandname: MARATHON
- manufacturername: MARATHON
X210 48A11O1068 1/4 Hp 208-230 48Y FR. 1075/2 Rpm
- Brand: Marathon Electric
- PartNumber: X210
- PackageQuantity: 1
- Manufacturer: Marathon Electric
- Label: Marathon Electric
Attributes
| Key | Value |
|---|
| Alternate Mfr Part Numb. | 048A11O1068 |
| Amps | 2-2.2 |
| Approvals | CSA, UR |
| Bearing Type | Ball |
| Bearings | Ball |
| Capacitor | 5MFD/370VAC Required |
| Composition | Rolled Steel |
| Current Rating | 2.0 to 2.2 A |
| Duty Cycle | Continuous |
| Efficiency | 0.544, 54.4 |
| Efficiency % | 54.4 % |
| Enclosure | Open Air Over |
| Enclosure Material | Steel |
| Enclosure Type | OAO (Open Air Over), Op. |
| Family Series | Marathon Electric Motors |
| Frame | 48Y |
| Frequency | 60 Hz |
| Gross Weight | 0 lbs |
| Horsepower | 1/4 hp |
| Horsepower Rating | 0.25 HP |
| HP | 1/4 |
| Hz | 60 |
| Insulation Class | B |
| Insulation Type | Class B |
| Item Number | X210 |
| Kilowatts | 0.19 kW |
| Manufacturer | Marathon Electric |
| Manufacturer Model # | 048A11O1068 |
| Manufacturer Part Number | 048A11O1068 |
| Maximum Ambient Tempera. | 40? C |
| Motor Diameter | 5-5/8" |
| Motor Shell Length | 3.62" |
| Mounting | Bracket |
| Mounting Orientation | Horizontal |
| Mounting Type | Three Lug Mount |
| Net Weight | 12 lbs |
| Number of Poles | 6 |
| Number of Speeds | 2 |
| Overall Length | 8.44 ", 8.44" |
| Phase | 1, 1 Phase |
| Product Type | PSC (Permanent Split Ca. |
| Rotation | Reversible |
| RPM | 1075 RPM, 1075, 1,075 R. |
| Service Factor | 1 |
| Shaft Diameter | 0.5 ", 1/2" |
| Shaft Length | 4.31" |
| Ship Weight | 13 lbs. |
| Special Features | Service Factor - 1 |
| Standards | UL Recognized |
| Supply Voltage | 208-230 VAC |
| Thermal Protection | Automatic |
| Type | Permanent Split Capacit. |
| UPC Code | 722856041920 |
| Voltage (AC) | 208-230 VAC |
| Volts | 208, 230 |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
 | Galco | X210-MARA | 188.5 | 60 | In Stock | | Marathon Electric | 12.0 | 188.5 @ 60 |
 | emotorpro.com | X210 | 202.18 | 1 | In Stock | | Marathon | 13.0 | 202.18 @ 1 |
| us.rs-online.com | 72238279 | 225.84 | 1 | In Stock | | Marathon Motors | | 225.84 @ 1 |
