Orion Fans OA825AP-22-1TB

B086BR3TRD

OA825AP-22-1TB, AC Fan Axial Ball Bearing 230V 160V to 260V 25CFM 28dB 80 X 80 X 27mm High Speed (5 Items)

OA825AP-22-1TB, AC Fan Axial Ball Bearing 230V 160V to 260V 25CFM 28dB 80 X 80 X 27mm High Speed (5 Items)zoom

Attributes

Key Value
Air Flow25 CFM
ApprovalscUR, TUV, UR
Approximate Size3.2 x 3.2 in. ; 80 x 80.
Approximate Thickness1 in. ; 26 mm
ASINB005T8VQ56
Batteries Required?No
Bearing TypeBall
CertificationRoHS
ConfigurationSquare
Dimensions3.2 x 3.2 x 1 . ; 80 x .
Family SeriesOrion Fans, AC-FAN Seri.
Fan Speed3,000 RPM
Fan TypeAC
Gross Weight0 lbs
Impeller MaterialPlastic
Item model numberOA825AP-22-1TB
Item NumberOA825AP-22-1TB
Item Package Quantity1
ManufacturerOrion
Manufacturer Part NumberOA825AP-22-1TB
MaterialDiecast Aluminum
Maximum Operating Tempe.80 C
Minimum Operating Tempe.-20 C
Net Weight0.57 lbs
Noise Level28 dB, 28 dBA
Nominal Depth25 mm
Nominal Height80 mm
Nominal Voltage240 VAC
Nominal Width80 mm
Operating Temp Range (F)-4-176 ?F
Operating Voltage230 VAC
Part NumberOA825AP-22-1TB
Power Consumption9 W
Power Rating9 W
Product SeriesAC-FAN
RoHSYes
RotationCW
SeriesOA825 Series
Size3.2 x 1 (80 x 25) In. (.
Speed3000 RPM
Static Pressure0.21 in H2O (52.3 Pa)
Tachometer OutputNo
TerminationTerminals
TypeSquare
UsagePersonal
Voltage Rating230 V

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
ArrowOA825AP-22-1TB6.439142Orion6.439 @ 1
Onlinecomponents.comOA825AP-22-1TB14.36136ORION FANS14.36 @ 1
Heilind ElectronicsOA825AP-22-1TB16.0139ORION FANS16.0 @ 1
thumbzoomDigi-Key1053-1098-ND16.291In StockOrion Fans16.29 @ 1
thumbzoomjensentools.com1014142420.01In StockOrion Fans20.0 @ 1
us.rs-online.com7010334120.3619Orion Fans20.36 @ 1
thumbzoomNewark51AK157022.1512ORION FANS22.15 @ 1
AmazonB005T8VQ5622.271In StockOrion22.27 @ 1
thumbzoomGalcoOA825AP-22-1TB-ORIN23.531In StockOrion0.5723.53 @ 1
Future Electronics247499724.21620In StockOrion Fans24.216 @ 20
