CAI - SQUARE D BDA24045Y1

B07JVFBCDV

Square D Circuit Breaker, 45 Amps, Number of Poles: 2, 277/480VAC AC Voltage Rating

Square D Circuit Breaker, 45 Amps, Number of Poles: 2, 277/480VAC AC Voltage Ratingzoom

Attributes

Key Value
9 Mm Pitches6
[Ics] Rated Service Bre.25 kA 220...240 V AC 50.
[Ue] Rated Operational .525 V AC 50/60 Hz UL 489
[Ui] Rated Insulation V.800 V IEC 60947-2
[Uimp] Rated Impulse Wi.8 kV IEC 60947-2
AC Voltage Rating525V AC
Ambient Air Temperature.-25-70 ?C
Ambient Air Temperature.-50-85 ?C
Amps45 A
Awg GaugeAWG 14...AWG 2/0 alumin.
Breaking Capacity25 kA 208Y/120 V AC 50/.
Breaking Capacity CodeD
California Proposition .DINP, which is known to.
China Rohs RegulationProduct out of China Ro.
Circuit Breaker ActuatorToggle
Circuit Breaker Mountin.I-Line
Circuit Breaker TypeStandard
ColorGray RAL 7016)
Connection Pitch27 mm
Continuous Current Rati.80 %
Control TypeToggle
Curve TypeB
DC Voltage RatingNot Rated
Depth3.5 in, 89 mm
Device Applicationdistribution
Device Short NameBD 045
Electrical ConnectionI-Line connection line .
Electrical Durability10000 cycles IEC 947-1 .
Environmental DisclosureENVPEP1610005EN
Eu Rohs DirectiveCompliant
For Use WithElectrical Distribution.
Frame Size125A/BD
Halogen Content Perform.Halogen free product
Height5.39 in, 137 mm
Ik Degree Of ProtectionIK07 IEC 62262
Instantaneous TripFixed
Ip Degree Of Protectionfront cover IP40 IEC 60.
ItemMolded Case Circuit Bre.
Line Rated Current45-45 A
Local Signallingpresence of auxiliary c.
Max. AIR Rating25kA at 277/408V AC
Max. Wire Size2 AWG
Mechanical Durability20000 cycles IEC 947-1 .
Mercury FreeYes
Min. Wire Size14 AWG
Mounting Height76.2 mm
Mounting ModeI-Line
Net Weight0.952 kg
Network Frequency50/60 Hz
Number of Poles2
Number Of Slots1 auxiliary switch OF p.
Phase1
Phase ConnectionAB
Poles Description2P
Pollution Degree3 IEC 60947-1
Product CertificationsUL || IEC || CCC || EAC.
Product NamePowerPact B
Product Or Component Ty.circuit breaker
Pvc FreeYes
Quality LabelsCE
Quantity Per Setset of 1
RangePowerPact
Reach RegulationReference contains Subs.
Rohs Exemption Informat.Yes
SeriesBDA
StandardsCSA C22.2 No 5, EN/IEC .
Suitability For Isolati.yes IEC 60947-2
Sustainable Offer StatusGreen Premium product
Terminal ConnectionAl Mechanical Lug OFF E.
Tightening Torque3.6-4.4 N.m 2.5-6 mm? (.
Trip TypeThermal Magnetic
Trip Unit Technologythermal-magnetic
Utilisation Categorycategory A
Width2.13 in, 54 mm
Wire Stripping Length20 mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomgordonelectricsupply.comBDA24045Y1615.01In Stock10SQUARE D615.0 @ 1
thumbzoomZoroG6322272759.321In Stock65Square D759.32 @ 1
thumbzoommayerelectric.comSQDBDA24045Y1928.711In StockSQUARE D2.0944928.71 @ 1
