Triad Magnetics VPL12-4000

B00MEJM0OY

VPL12-4000

VPL12-4000zoom

Attributes

Key Value
Available Voltage115 ; 230 V
CategoryTransformers
Center TapNo
ConfigurationSplit Bobbin
Current - Output (Max)3.97A
DescriptionPWR XFMR LAMINATED 50.0.
Digi-Key Part Number237-1635-ND
Dimensions4 W x 2.562 H x 2.25 D .
Frequency50/60 Hz
Height - Seated (Max)65.09mm
Lead Length8 "
ManufacturerTriad Magnetics
Manufacturer Product Nu.VPL12-4000
Manufacturer Standard L.23 Weeks
MfrTriad Magnetics
Mounting Hole Size3.562 in
Mounting TypePanel Mount, Chassis Mo.
Needed Voltage6.3 VAC ; 12.6 VAC
Number of Outlets4
PackageBox
Phase1 Phase
Power - Max50.0VA
Power Rating50 VA
Primary TypeIndustrial Transformer
Primary Voltage115/230 VAC
Primary Winding(s)Dual
Product HeaderWorld Series? Dual Bobb.
Product StatusActive
Secondary Current7.94/3.97 A
Secondary Voltage6.3/12.6 VAC
Secondary Winding(s)Dual
SeriesChassis Mount: World Se.
Size / Dimension57.15mm L x 101.6mm W
StandardsUL
TerminationLead Wires
Termination StyleWire Leads
TypeLaminated Core, Power T.
Voltage - Isolation3500Vrms
Voltage - Primary115V, 230V
Voltage - Secondary (Fu.12.6V
Weight2.3 lb, 2.3 lbs (1 kg)

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
WaldomTRIAD VPL12-400015.461In StockTriad15.46 @ 1
Onlinecomponents.comVPL12-400018.921In StockTRIAD Magnetics18.92 @ 1
Future Electronics407202219.4888In StockTriad Magnetics19.488 @ 8
HotendaH424816020.961In StockTriad Magnetics20.96 @ 1
thumbzoomDigi-Key483509521.71In StockTriad Magnetics2.321.7 @ 1
us.rs-online.com7021819822.341In StockTriad Magnetics2.322.34 @ 1
thumbzoomNewark25H823228.191In StockTRIAD MAGNETICS28.19 @ 1
