- mpnLPC2388FBD144.551
- brandname: NXP
- manufacturername: NXP
LPC2388FBD144 - Microcontroller - MCU 64-Pins LQFP 2388 (3 Piece Lot)
- Brand: Generic
- PartNumber: LPC2388FBD144
- Model: LPC2388FBD1
- Binding: Electronics
- Manufacturer: NXP Semiconductors BV
- Label: NXP Semiconductors BV
Attributes
| Key | Value |
|---|
| ADC Channels | ADC Channels |
| ADC Resolution | 10bit |
| ADCs | 8 x 10 bit |
| Alternate Part No. | 771-LPC2388FBD144-S |
| Brand | Brand, NXP Semiconducto. |
| Core | ARM7TDMI-S |
| Data Bus Width | 32bit, 16 bit/32 bit |
| Data RAM Size | 98 kB |
| Device Core | Device Core |
| Dimensions | Dimensions |
| Family Name | Family Name |
| Height | 1.45mm |
| Instruction Set Archite. | RISC |
| Interface Type | CAN, I2C, I2S, SPI, SSP. |
| Length | 20 mm, Length |
| Manufacturer | NXP |
| Manufacturer Part No. | LPC2388FBD144,551 |
| Maximum Clock Frequency | 72 MHz |
| Maximum Frequency | Maximum Frequency |
| Maximum Operating Tempe. | + 85 C, +85 ?C |
| Minimum Operating Tempe. | - 40 C, Minimum Operati. |
| Mounting Style | SMD/SMT |
| Mounting Type | Surface Mount |
| Number of ADC Units | 1 |
| Number of CAN Channels | Number of CAN Channels |
| Number of Ethernet Chan. | Number of Ethernet Chan. |
| Number of I/Os | 104 I/O |
| Number of I2C Channels | Number of I2C Channels |
| Number of LIN Channels | Number of LIN Channels |
| Number of PCI Channels | 0 |
| Number of PWM Units | 1 |
| Number of SPI Channels | Number of SPI Channels |
| Number of Timers | Number of Timers, 4 Tim. |
| Number of UART Channels | 4 |
| Number of USART Channels | Number of USART Channels |
| On-Chip DAC | With DAC |
| Operating Supply Voltage | 3 V to 3.6 V |
| Package Type | LQFP |
| Package/Case | SOT-486 |
| Packaging | Tray |
| Part # Aliases | LPC2388FBD144-S |
| Pin Count | Pin Count |
| Processor Series | LPC23 |
| Product Category | ARM Microcontrollers - . |
| Program Memory Size | 512 kB, Program Memory . |
| Program Memory Type | Flash, Program Memory T. |
| Pulse Width Modulation | 1(Motor Control) |
| PWM Channels | 1 |
| RAM Size | RAM Size |
| Series | LPC2000 |
| Stock | Stock |
| Timer Resolution | Timer Resolution |
| Timers | Timers |
| Tradename | LPC |
| Typical Operating Suppl. | Typical Operating Suppl. |
| USB Channels | USB Channels |
| Width | 20.1mm |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
| Hotenda | H2310139 | 14.68 | 1 | 1834 | | NXP Semiconductors | | 14.68 @ 1 |
| Newark | 85AK8434 | 16.26 | 60 | In Stock | | NXP | | 16.26 @ 50 |
 | Digi-Key | 568-4323-ND | 17.97 | 1 | In Stock | | NXP USA Inc. | | 17.97 @ 1 |
 | RS Delivers | 725-7799 | 21.084 | 1 | 6 | | NXP | | 21.084 @ 1 |
 | swatee.com | LPC2388FBD144,551 | 25.65 | 1 | 141 | | NXP | | 25.65 @ 1 |
