Burndy KA29U

B00GPPZHNE

KA29U, Screw Terminal 6AWG Aluminum 51mm Tin

KA29U, Screw Terminal 6AWG Aluminum 51mm Tinzoom

Attributes

Key Value
Aluminum Size (Range)6 STR - 250 kcmil
ApplicationFor Aluminum And Copper.
ARRA CompliantYes
Base Unit of MeasureEA
Body MaterialAluminum
Bolt Hole Size5/16
BOX SIZE0.000x0.000x0.000 (in)
BrandBurndy Canada
Buy American CompliantYes
Carton25
Carton - Gross Weight p.0.000 lb.
Carton - Number of Sub .400
Carton - Pack Descripti.Carton
Carton - SCC-14 Next Lo.00781810370155
Carton - Total Units400 EA
Case - SCC-14 Next Lowe.30781810370156
Category DescriptionComp & Mech Lugs and Bu.
Certification AgencyProposition 65
ChannelSightWidgetId705
Class CodeB51
ClassificationComp & Mech Lugs and Bu.
Compatible with Product.Aluminum Cable, Copper .
Conductor - AL Str Size6;4;3;2;1;1/0;2/0;3/0;4.
Conductor - AL Str Size.6-250
Conductor - Copper Str .6;5;4;3;2;1;1/0;2/0;3/0.
Conductor - Copper Str .6-250
Conductor - Nominal Dia.0.184, 0.184, 0.206, 0..
Conductor MaterialCopper;Aluminum
Conductor Size6 AWG-250 kcmil
Conductor TypeAL C Str-Size;CU C Str-.
Connection OrientationDual Rated Lug
Connector TypeTerminal, Lug
Contact FinishTin
Copper Solid Size (Rang.N/A
Copper Stranded (Range)6-250
Country of OriginMX - Mexico, MX
CSA ApprovedYes
Description6STR-250 Dual Rated
Description - Invoice6STR-250 Dual Rated
Description - Slang1 Cable to Flat
Dimension - Bolt Hole S.0.31 in
Dimension - Bolt Size f.5/16, 2023-05-16
Dimension - D inch0.94 in
Dimension - Height frac.1.14 in
Dimension - Height inch1.14 in
Dimension - Hole Size i.0.33 in
Dimension - Hole Size mm8 mm
Dimension - L Length Ov.51 mm
Dimension - Length Over.2.00 in
Dimension - N inch0.47 in
Dimension - Pad Width i.1.02 in
Dimension - Stud Size i.5/16, 45062
Dimension - Width inch1.00 in
Dimension - Width mm25 mm
Each - Number of Sub Pa.1
Each - Pack DescriptionEach
Each - Width1.02 in
ECCNEAR99
EU RoHS IndicatorYes
extra long descriptionBUR KA29U 6STR-250 DUAL.
FeaturesThese Dual-Rated One-Co.
For Conductor MaterialAluminum, Copper
For Stranded Copper Wir.250 kcmil
For Stranded Copper Wir.6 AWG
For Stud Size5/16 in, 5/6 in
for use withAluminum to Aluminum Co.
For Wire Size1/0 AWG, 2 AWG, 2/0 AWG.
Freight Class Code16027000
GTIN00781810370155
Harmonization Code8535908020
Head StyleHex
Hole Diameter0.33 in
Hole SpacingNot Applicable
Image Actual Or Represe.A
Industry Standard(s)UL 486A-486B
Installation Torque275
Installation Torque Rec.275 LBS/in
Insulated/Non-InsulatedNon-Insulated
ItemMechanical Connector
Lead Time10 wk
Length2.0 in
Length (Straight Wirewa.2.0 in
Long DescriptionConductor Lug, #6 AWG (.
Lowest Level UOMEach
Lug Wire Size6 AWG-250 kcmil
Manufacturers Part Numb.KA29U
MaterialTin Plated Aluminum, Al.
Material - HardwareAluminum
Max. Conductor Size250 kcmil Stranded
Maximum Conductor Size250 kcmil (Stranded)
Maximum Operating Tempe.+194 ?F, 194 Degrees F
Maximum Voltage600 V
Min. Conductor Size6 AWG Stranded
Minimum Conductor Size#6 AWG (Stranded)
MSDS FlagNo
No. of Conductors1
No. of Wires1-Wire
Number of Conductors1
Number Of Conductors1
Number of Conductors/Po.1
Number of Holes1
Number of Terminations1
Order Multiple25 EA
Overall Depth1 1/16 in
Overall Length2 in, 2 in;51 mm
Overall Width1.14 in
Package - Gross Weight .2.875 lb.
Package - GTIN - Package30781810370156
Package - Number of Sub.25
Package - Pack Descript.Package
Package - SCC-14 Next L.00781810370155
Package - Total Units25 EA
Package Height9.375 in
Package Length2 in
Package Quantity25 EA
package quantity400 CT
Package Weight2.875 lb.
Package Width3.25 in
Physical Attribute - Nu.1
Physical Attribute - Nu.1
Physical Attribute - Sc.Allen
PlatedY
Plated (Yes or No)Y
Plating TypeTin
Product MaterialAluminum
Product TypeTerminal, Conductor Lug
Short DescriptionConductor Lug, Non-Insu.
Special FeaturesThese Dual-Rated Two Co.
Special Features : Feat.0.25 in
StandardUL 486A-486B
standardUL 486A-486B
Standard Package Quanti.25
StandardsCSA Certified, UL Listed
Standards - Industry St.UL 486A-486B
Standards - RoHS Compli.EX
Standards MetRoHS Compliant;UL Liste.
Stock IndicatorS - Shelf Stock
Stud Size5/16 in., 5/16 in
sub brandBurndy
Sub BrandUNIVERSAL TERM
Sub Class CodeB51BGEF
Temperature Rating194
Terminal TypeScrew
These Dual-Rated One-Co.0.25 in
Tongue Length0.94 in
Tongue Thickness0.25 in
Tongue Width1.02 in
Torque275 in-lb
TypeBolted Lugs & Terminals
Type of PlatingTin
UL ListedYes
UL Listed Direct BurialNo
UNSPSC39121408 - Mechanical c.
UPC781810370155
Use WithAluminum and Copper Con.
Weight per each0.115
Width1.02 in, 1.14 in
Wire Size Ranges6 AWG - 250 kcmil

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
steinerelectric.com194922.7916BURNDY2.79 @ 6
thumbzoomKelly HayesKA29U5.591176Burndy5.59 @ 6
kirbyrisk.com5393606.3416Burndy6.34 @ 6
Graybar880475927.15681181Burndy7.1568 @ 6
thumbzoomusmegastore.comKA29U8.2916Burndy8.29 @ 6
ArrowKA29U8.4256Burndy8.4 @ 25
thumbzoomZoroG46844439.051983Burndy2.889.05 @ 6
thumbzoomUnited Electric706839.2816BURNDY9.28 @ 6
thumbzoomElliott ElectricKA29U10.5316Burndy0.11510.53 @ 6
thumbzoommayerelectric.comBURKA29U11.82195BURNDY2.87511.82 @ 6
us.rs-online.com7148644112.07165BURNDY12.07 @ 6
thumbzoomRaptor SuppliesAB6RDB18.65974516BURNDY18.659745 @ 6
