Martin 120CTB35

B00452UQ2Q

Martin Roller Chain Sprocket, Taper Bushed, Type C Hub, Single Strand, 120 Chain Size, For 3020 Bushing, 1.5" Pitch, 35 Teeth, 3" Max Bore Dia., 17.567" OD, 5.25" Hub Dia., 0.924" Width

Martin Roller Chain Sprocket, Taper Bushed, Type C Hub, Single Strand, 120 Chain Size, For 3020 Bushing, 1.5" Pitch, 35 Teeth, 3" Max Bore Dia., 17.567" OD, 5.25" Hub Dia., 0.924" Widthzoom

Attributes

Key Value
Bore TypeTaper Bush, Bushed
bore type:Bushed
bushing bore range:15/16 to 3 in
Bushing Code3020
Bushing SizeTB Bushed 3020
bushing size:3020
bushing type:Taper Locking
Caliper Diameter15.8419
caliper diameter:15.8419 in
chain / sprocket type:Standard Roller Chain
Chain Number120
chain number & pitch:120 / 1-1/2 in
Chain Pitch1.5 in
Country of Origin (subj.United States
hardened teeth:Non-Hardened Teeth
hub diameter:5-1/4 in
Length through Bore (In.2
length through bore:2.0000 in
manufacturer upc number:697950032900
MaterialSteel
material:Steel
number of hubs:2
Number of Rows1
number of strands acros.1
Number of Teeth35
Number Of Teeth35
number of teeth:35
Outside Dia17.566"
Outside Dia. (In.)17.566
outside diameter:17.5660 in
overall width:2 in
Pitch1.5 in, 1.500 in., 1.5
Pitch Dia.16.7337
pitch diameter:16.7337 in
pitch type:Single
SizeTB Bushed 3020
storage dimension heigh.2.0000 in
storage dimension lengt.17.5660 in
storage dimension width:17.5660 in
Storage Height2
Storage Length17.566
Storage Width17.566
Surface TreatmentProtective Coating
surface treatment:Protective Coating
tooth width:0.924 in
TypeBushed Roller Chain Spr.
Weight53.85
weight:53.85 lbs

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
AmazonB00452UQ2Q450.011In StockMartin450.01 @ 1
thumbzoomindustrialzone.com120CTB35571.371In StockMartin1.0571.37 @ 1
thumbzoomMRO Supply259130602.721In StockMartin Sprocket602.72 @ 1
us.rs-online.com72319191680.481In StockMartin Sprocket & Gear680.48 @ 1
thumbzoomPurvis120CTB35700.541In StockMartin700.54 @ 1
thumbzoomapexindustrialautomation.com120CTB35747.741In StockMartin Sprocket747.74 @ 1
thumbzoommotionindustries.com00174293828.661In StockMartin828.66 @ 1
thumbzoomZoroG33416711072.21In Stock10Martin Sprocket & Gear53.851072.2 @ 1
