TE Connectivity MTL206P

mpn3-1437559-9
brandname: TE Connectivity / AMP Brand
manufacturername: TE Connectivity / AMP Brand

MTL-206P

MTL-206P

zoom

Brand: TE Connectivity
PartNumber: MTL206P
Model: MTL206P
PackageQuantity: 1
Binding: Electronics
Manufacturer: TE CONNECTIVITY
Label: TE CONNECTIVITY

Attributes

Key	Value
Actuator Length	17.00mm
Actuator Material	Copper Alloy, Chrome Pl.
Actuator Type	Bat, Locking Lever
Alternate Mfr Part Numb.	3-1437559-9
Base Product Number	MTL206
Brand	TE Connectivity
Bushing Thread	1/4-40
Category	Switches
Circuit	DPDT
Color	Green
Color Family	Green
Contact Configuration	DPDT
Contact Current Rating	4 A @ 28 V dc
Contact Form	DPDT
Contact Resistance	1?
Country of Origin (subj.	United States
Current Rating	6 A
Current Rating (Amps)	6A (AC), 4A (DC)
Dielectric Strength	1000 VAC
ECCN	EAR99
Electrical Life	60,000 Cycles
Features	Epoxy Sealed Terminals
Illumination	Non-Illuminated
Illumination Type, Color	-
Illumination Voltage (N.	-
Ingress Protection	-
Manufacturer P/N	3-1437559-9
Maximum Operating Tempe.	+80?C
Mfr	TE Connectivity ALCOSWI.
Minimum Operating Tempe.	-20?C
Mounting Hole Size	0.25 in
Mounting Type	Panel Mount
Number of Poles	2
Number of Positions	3
Operating Temperature	-20?C ~ 80?C
Operating Temperature R.	-20 ? +80?C
Operation	On-Off-On
Pack Quantity	1
Package	Bulk
Panel Cut Out Diameter	0.25in
Panel Cut Out Size	0.25in
Panel Cutout Dimensions	Circular - 6.40mm Dia
Product Status	Active
Schedule B Code	8536.50.9065
Series	MTL Green, MT Series
Shipping Weight	0.03 pounds
Switch Function	On-Off-On
Switch Operation	On-Off-On
Terminal Type	Solder
Termination	Solder Lugs
Termination Style	Solder Lug
Type	Toggle
Voltage Rating	125 V
Voltage Rating - AC	125 V
Voltage Rating - DC	28 V

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	marvac.com	27833	13.95	1	13		Alcoswitch		13.95 @ 1
	Component Electronics	170-187	15.38	1	In Stock		Tyco Electronics		15.38 @ 1
	Verical	3-1437559-9	20.378	3	48		TE Connectivity / AMP		20.378 @ 3
	Mouser	506-MTL206P	27.96	1	113		TE Connectivity / AMP		27.96 @ 1
	Waldom	TE CONNECTIVITY AMP BRAND 3-1437559-9	29.84	2	69		TE CONNECTIVITY/AMP BRAND		29.84 @ 2
	Onlinecomponents.com	MTL206P	31.22	1	18		TE Connectivity / AMP		31.22 @ 1
	RS Delivers	783-1157	32.736	1	In Stock		TE Connectivity		32.736 @ 1
	Newark	36AC2963	40.29	50	58		AMP - TE CONNECTIVITY		40.29 @ 50
	us.rs-online.com	70156017	42.9	1	36		TE Connectivity		42.9 @ 1
	Digi-Key	969615	43.092	1	57		TE Connectivity ALCOSWITCH Switches		43.092 @ 1
	Zoro	G000984284	48.97	50	In Stock		Te Connectivity		48.97 @ 50
	skygeek.com	SGP29175	49.29	1	In Stock		TE CONNECTIVITY	0.03	49.29 @ 1
