Woodhead / Molex 1200710047

B07S964ZDN

1200710047, Conn M12 Circular PIN 5 POS ST Cable Mount 5 Terminal 1 Port Micro-Change

1200710047, Conn M12 Circular PIN 5 POS ST Cable Mount 5 Terminal 1 Port Micro-Changezoom

Attributes

Key Value
Alternate Mfr Part Numb.8A5006-32
Amperage Rating4
ApplicationsIndustrial
Backshell Material, Pla.Polyamide (PA), Nylon
Base Product Number120071
Cable external diameter4.1...8.1mm
Cable Opening0.161" ~ 0.319" (4.10mm.
Cable Size3.3 to 6.6
CategoryConnectors, Interconnec.
ColorBlack, Silver
Connectorplug
Connector seriesMicro-Change
Connector TypeReceptacle, Male Pins
Contact Finish - MatingSilver
Contact Finish Thicknes.-
Contact MaterialCopper Alloy
Current Rating (Amps)4A
DescriptionCONN RCPT MALE 5POS SIL.
Detailed Description5 Position Circular Con.
Digi-Key Part NumberWM9317-ND
Electrical mountingscrew terminal
Engineering PN8A5006-32
Environmental Conditions-25 to 90 deg C Tempera.
Family NameMicro-Change (M12)
Fastening TypeThreaded
FeaturesBackshell
GenderDouble-Ended ; Female
Ingress ProtectionIP67 - Dust Tight, Wate.
Insert MaterialPolyamide (PA), Nylon
IP RatingIP67
IP ratingIP67
Kind of connectormale
Locking systemexternal thread,
ManufacturerMOLEX
Manufacturer Product Nu.1200710047
Manufacturer Standard L.13 Weeks
Material Flammability R.-
Mating TypeThreaded
Max. operating voltage36V DC
Maximum current4A
Mechanical mountingfor cable
MfrMOLEX
Mounting Feature-
Mounting TypeFree Hanging (In-Line),.
Number of Contacts5
Number of pins5
Number of Positions5
O-Ring MaterialNitrile
Operating Temperature-25?C ~ 90?C
Operating temperature-25...90?C
Orientationstraight, Keyed
PackageBulk
PolarisationA code - DeviceNet / CA.
Primary MaterialMetal
Primary TypeM12
Product StatusActive
SeriesBrad Micro-Change 12007.
Shell FinishNickel
Shell MaterialBrass
Shell Size - InsertM12-5
Shell Size, MIL-
Shielding-
Spatial orientationstraight
Special FeaturesLow-Halogen
TerminationScrew
Thread SizeM12
TypeStraight Male, Micro
Type of connectorM12
UPC Code78172553221
Voltage Rating30VAC, 36VDC, 30 VAC/36.
Wire cross-section0.75mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomFrench GerlemanWOOD8A50063211.261146Woodhead11.26 @ 1
thumbzoomTMEMX-120071004712.94111MOLEX12.94 @ 1
Radwell120071004719.421In StockMOLEX19.42 @ 1
thumbzoomWalker Industrial120071004722.74In Stock17Molex22.7 @ 4
WaldomMOLEX WOODHEAD 120071004724.633114MOLEX / WOODHEAD24.63 @ 3
Onlinecomponents.com120071004728.7314Molex28.73 @ 1
Mouser538-120071004729.45123Molex29.45 @ 1
HotendaH107450930.541In StockMolex30.54 @ 1
thumbzoomjensentools.com1020334032.84199Molex32.84 @ 1
thumbzoomNewark72AC722934.61146MOLEX34.61 @ 1
thumbzoomZoroG207945138.153In StockMolex / Woodhead38.15 @ 3
us.rs-online.com7037859938.81120Molex Woodhead/Brad38.81 @ 1
thumbzoomDigi-Key207633038.81131Molex38.81 @ 1
thumbzoomstandardelectricsupply.com535695630.51In StockWoodhead630.5 @ 1
