ANALOG DEVICES ADG509FBRWZ

mpnADG509FBRWZ
brandname: Analog Devices Inc.
manufacturername: Analog Devices Inc.

ADG509FBRWZ

ADG509FBRWZ

zoom

Brand: ANALOG DEVICES
PartNumber: ADG509FBRWZ
Size: 1 Piece
PackageQuantity: 1
Manufacturer: Analog Devices
Label: Analog Devices

Attributes

Key	Value
-3db Bandwidth	-
Alternate Part No.	584-ADG509FBRWZ
Base Product Number	ADG509
Brand	Analog Devices
Category	Integrated Circuits (IC.
Channel Capacitance (CS.	3pF, 12pF
Channel-to-Channel Matc.	8.1Ohm
Charge Injection	15pC
Crosstalk	-
Current - Leakage (IS(o.	1nA
Manufacturer	Analog Devices Inc.
Manufacturer Part No.	ADG509FBRWZ
Maximum Operating Tempe.	+ 85 C
Maximum Power Dissipati.	3.3 mW
Mfr	Analog Devices Inc.
Minimum Operating Tempe.	- 40 C
Mounting Style	SMD/SMT
Mounting Type	Surface Mount
Multiplexer/Demultiplex.	4:1
Number of Circuits	2
Number of Switches	4
Off Time - Max	130 ns
On Resistance - Max	300 Ohms
On Time - Max	230 ns
On-State Resistance (Ma.	270Ohm (Typ)
Operating Supply Voltage	15 V
Operating Temperature	-40?C ~ 85?C (TA)
Package	Tube
Package / Case	16-SOIC (0.295", 7.50mm.
Package/Case	SOIC-16
Packaging	Tube
Product Category	Analogue Switch ICs
Product Status	Active
Series	-, ADG509F
Supplier Device Package	16-SOIC
Supply Current	0.1 uA
Supply Current - Max	1 uA
Supply Voltage - Max	16.5 V
Supply Voltage - Min	10.8 V
Switch Circuit	SP4T
Switch Time (Ton, Toff).	230ns, 130ns
Voltage - Supply, Dual .	?15V
Voltage - Supply, Singl.	15V

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	Hotenda	H2414525	7.87	1	49		Analog Devices, Inc.		7.87 @ 5
	swatee.com	ADG509FBRWZ	11.41	1	30		Analog Devices Inc.		11.41 @ 5
	Newark	53AK9189	12.8	1	92		ANALOG DEVICES		12.8 @ 5
	Digi-Key	997768	14.61	1	5		Analog Devices Inc.		14.61 @ 5
