PTVS10-058C-TH-BOURNS

B011OWSQ6W

BOURNS PTVS10-058C-TH TVS DIODE, 58V, BIDIR, AXIAL

BOURNS PTVS10-058C-TH TVS DIODE, 58V, BIDIR, AXIALzoom

Attributes

Key Value
ApplicationsGeneral Purpose
Base Product NumberPTVS10
Bidirectional Channels1
Breakdown Voltage70 V
Capacitance7.5 nF
Capacitance @ Frequency7500pF @ 10kHz
CategoryCircuit Protection
Clamping Voltage110 V
ConfigurationSingle
Current - Peak Pulse (1.10000A (10kA) (8/20?s)
DescriptionTVS DIODE 58VWM 110VC A.
Detailed Description110V Clamp 10000A (10kA.
Digi-Key Part NumberPTVS10-058C-TH-ND
Dimensions5 x 11.5 x 12 mm
Length0.196 in
ManufacturerBourns Inc.
Manufacturer Product Nu.PTVS10-058C-TH
Manufacturer Standard L.8 Weeks
Maximum Junction Temper.125 ?C
Maximum Operating Tempe.+125 ?C
MfrBourns Inc.
Minimum Operating Tempe.-40 ?C
Mounting TypeThrough Hole
Number of Pins2
Operating Temperature-55?C ~ 125?C (TJ), -40.
PackageTray
Package / CaseAxial, Right Angle Bend.
Package Type10058
Peak Current10 kA
Power - Peak Pulse-
Power Line ProtectionNo
Primary TypeDiodes
Product StatusActive
Reverse Current10 ?A
SeriesPTVPTT Series, PTVS
Stand Off Voltage58 V
Supplier Device PackageAxial
Surge Current10 kA
Temperature Operating R.-40 to +125 ?C
TypeTVS, Zener
Voltage - Breakdown (Mi.64V
Voltage - Clamping (Max.110V
Voltage - Reverse Stand.58V (Max)

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Onlinecomponents.comPTVS10-058C-TH17.091In StockBourns17.09 @ 1
thumbzoomNewark28X824420.5710In StockBOURNS20.57 @ 10
HotendaH65608420.681In StockBourns, Inc.20.68 @ 1
us.rs-online.com7034443321.15110Bourns21.15 @ 1
thumbzoomDigi-Key457198821.29110Bourns Inc.21.29 @ 1
