Burndy YAL1CT14

B084L71MN9

BURNDY YAL1CT14 Compression Lug 1AWG 1/4IN Stud Size 1HOLE Green

BURNDY YAL1CT14 Compression Lug 1AWG 1/4IN Stud Size 1HOLE Greenzoom

Attributes

Key Value
Certification - CSA App.Yes
Certification - cULusNo
Certification - ETLNo
Certification - UL Reco.No
Color CodeGreen
Conductor - Copper DLO .N/A
Conductor - Copper Str .1 AWG
Conductor - Copper Str .1 AWG
Conductor - MaterialCopper
Connector TypeTerminal
Die Index11
Dimension - B Length in.0.88 in
Dimension - Bolt Hole S.0.27 in
Dimension - D inch0.56 in
Dimension - Hole Size mm7 mm
Dimension - L Length Ov.46 mm
Dimension - Length Over.1.81 in
Dimension - N inch0.25 in
Dimension - Outside Dia.0.46 in
Dimension - Pad Width i.0.68 in
Dimension - Stud Size i.1/4
Feature - Barrel StyleChamfered
Feature - Barrel TypeStandard
MaterialCopper
Physical Attribute - Nu.1
Physical Attribute - To.Straight
PlatedY
Plating TypeTin - Electro Plated
Rating - KVA35 kV
Rating - Minimum Voltage600
Standards - RoHS Compli.CM
UL ListedYes
Voltage - Maximum35000

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomusmegastore.comYAL1CT1416.981In StockBurndy16.98 @ 1
