- mpn205-SL
- brandname: De-Sta-Co
- manufacturername: De-Sta-Co
De-Sta-Co Horizontal Handle Hold-Down Clamp, Solid-bar, Left flange base, w/60 lbs. cap., Steel (1 Each)
- Brand: De-Sta-Co
- PartNumber: 205-SL
- PackageQuantity: 1
- Binding: Tools & Home Improvement
- Manufacturer: Reid Supply Company
- Label: Reid Supply Company
Attributes
| Key | Value |
|---|
| Accommodates Workpiece . | No |
| Accomodates Workpiece V. | No |
| Application - Assembly | Excellent/High |
| Application - Checking . | Excellent/High |
| Application - Closures | Excellent/High |
| Application - Food Proc. | Fair/Medium |
| Application - Machining | Poor/Low |
| Application - Welding | Poor/Low |
| Application - Wood-Work. | Excellent/High |
| Arm and Tip Style | Solid Bar with Steel Tip |
| Arm Length | 0.73 in |
| Arm Movement | 94 |
| Arm Style | solid bar |
| Arm Type | Solid |
| Available | Upon Request |
| Bar Width (mm) | 6.35 |
| Base Mounting Style | flanged, left, Flange |
| Base Type | Left Flange |
| Base Width | 0.95, 24.1 |
| Body Material | Steel |
| Brand | Destaco |
| Clamp Arm Length (in) | 0.88 |
| Clamp Arm Opening Angle | 94 Degrees |
| Clamp Arm Style | solid bar |
| Clamp Bar Opening (+10?. | 94 |
| Duty Cycle | 2 |
| Fastener Thread Size | #8 in |
| Handle | Horizonal |
| Handle Design | Standard Horizontal Ha. |
| Handle Movement | 82 |
| Handle Opening (+10?) | 82 |
| Handle Orientation | Horizontal |
| Height Under Arm | 9.4, 0.370, 0.3 in |
| Height Under Clamp Arm . | 0.39 |
| Holding Capacity | 266.9, 60 |
| Includes Locking Handle | No |
| Item | Clamp Hold-Down Action . |
| Locking Handle Included | Standard |
| Max Arm Length | Less than 2" |
| Max Height Under Arm | Less than 1 |
| Maxmum Holding Capacity. | 61 |
| Mounting Hole Spacing A. | 0.620, 15.7 |
| Overall Depth | 0.67 in |
| Overall Height | .67, 17 |
| Overall Length | 70.6, 2.85 in, 2.78 |
| Overall Width | 0.72 in |
| Product Type | Clamp Hold-Down Action . |
| Service Environment | Normal |
| Spindle Material | Steel with Neoprene Tip |
| Spindle Thread Size | M4, 8-32,M4 |
| Spindle Type | Neoprene Tipped |
| Standard Material | Steel |
| Tip Diameter | 0.32 in |
| Tip Material | Neoprene |
| Toggle Lock Plus | No |
| Weight (lb) | 0.07 |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
| reidsupply.com | TC-205-SL | 18.77 | 1 | 12 | | Destaco | | 18.77 @ 1 |
 | freertool.com | DE-STA-CO-205-SL | 19.82 | 1 | In Stock | | DESTACO | 0.07 | 19.82 @ 1 |
 | kinequip.com | 205-SL | 20.01 | 1 | In Stock | | Destaco | | 20.01 @ 1 |
 | Zoro | G0579437 | 23.69 | 1 | In Stock | | De-Sta-Co | 0.1 | 23.69 @ 1 |
 | bscsource.com | 205SL | 27.39 | 1 | In Stock | | De-Sta-Co | | 27.39 @ 1 |
 | primebuy.com | 205-SL | 27.89 | 1 | In Stock | | Destaco | | 27.89 @ 1 |
 | National Supply Network | 99147464 | 35.13 | 1 | In Stock | | De-Sta-Co | | 35.13 @ 1 |
 | Raptor Supplies | AJ8BHF | 37.051326 | 1 | In Stock | | DESTACO | | 37.051326 @ 1 |
