Orion Fans OA172SAPL-22-1TB

B00Q7W6DK6

Fans Fan 172x38 220VAC Ball Term 228cfm

Fans Fan 172x38 220VAC Ball Term 228cfmzoom

Attributes

Key Value
Air Flow228 CFM, 211 CFM, 228.0.
Airflow215 CFM
Alternate Part No.670-OA172SAPL221TB
Approval AgencycURus, TUV
ApprovalscUR, TUV, UR
Approximate Size6.8 x 5.9 in. ; 172 x 1.
Approximate Thickness1.5 in. ; 38 mm
Base Product NumberOA172SAP
Bearing TypeDual Ball, Ball
BrandOrion Fans
CategoryFans, Thermal Management
ConfigurationObround (Flat Sides/Rou.
Connection Type0.120 in. Flat Blade
Current Rating (Amps)-
Current TypeAC
DescriptionFAN AXIAL 172X38.5MM 23.
Detailed DescriptionFan Tubeaxial 230VAC Re.
Digi-Key Part Number1053-1047-ND
Dimensions6.8 x 5.9 x 1.5 . ; 172.
Family SeriesOrion Fans, AC-FAN Seri.
Fan Speed3,400 RPM
Fan TypeTubeaxial, AC
FeaturesCapacitor, Thermal Over.
Frame Dimensions - mm172 mm x 38 mm x 150 mm
Frequency50;60 Hz
Gross Weight1.7 lbs
Height150 mm
Housing MaterialAluminum
Impeller MaterialPlastic
Ingress Protection-
Item NumberOA172SAPL-22-1TB
Length172 mm
Lifetime @ Temp.60000 Hrs @ 40?C
ManufacturerOrion Fans, Orion
Manufacturer Part No.OA172SAPL-22-1TB
Manufacturer Part NumberOA172SAPL-22-1TB
Manufacturer Product Nu.OA172SAPL-22-1TB
Manufacturer Standard L.19 Weeks
MaterialDiecast Aluminum
Material - BladePolybutylene Terephthal.
Material - FrameAluminum
Maximum Operating Tempe.80 C
MfrOrion Fans
Minimum Operating Tempe.-20 C
Net Weight1.7 lbs
Noise58.0dB, 58 dB*
Noise Level58 dB, 58 dBA
Nominal Depth38 mm
Nominal Height150 mm
Nominal Voltage240 VAC
Nominal Width172 mm
Operating Temp Range (F)-4-176 ?F
Operating Temperature-4 ~ 176?F (-20 ~ 80?C)
Operating Voltage230 VAC
PackageBox
Power (Watts)28.00W
Power Consumption28 W
Power Rating26 W, 28 W
ProductFans
Product CategoryAC Fans
Product SeriesAC-FAN
Product StatusActive
RoHSYes
RotationCCW
RPM3400 RPM
SeriesOA172SAPL Series, OA172.
Size6.8 x 5.9 x 1.5 (172 x .
Size / DimensionRectangular/Rounded - 1.
Speed3400 RPM
Static Pressure0.870 in H2O (216.7 Pa).
Supply Voltage230 V
Tachometer OutputNo
Termination2 Terminals, Terminals
Termination StyleTerminals
TypeObround (Flat Sides/Rou.
Voltage - Rated230VAC
Voltage Range160 ~ 260VAC
Voltage Rating230 V
Weight1.6 lbs (725.7 g)
Width38 mm, 38.50mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Onlinecomponents.comOA172SAPL-22-1TB35.88136ORION FANS35.88 @ 1
Heilind ElectronicsOA172SAPL-22-1TB40.51In StockORION FANS40.5 @ 1
thumbzoomNewark89AH239241.62240In StockORION FANS41.62 @ 240
thumbzoomCarlton Bates Company4030849519744.05114ORION FANS44.05 @ 1
Carlton-Bates4030849519744.161In StockOrion44.16 @ 1
thumbzoomarcade-electronics.comORI-OA172SAPL-22-1TB45.91In StockOrion Fans45.9 @ 1
thumbzoomkiesub.comOA172SAPL-22-1TB47.871In StockORION47.87 @ 1
AmazonTPB00DAN1PRG49.111In Stock2Knight Electronics49.11 @ 1
AmazonUNKB00DAN1PRG49.111In StockKnight Electronics49.11 @ 1
thumbzoomjensentools.com1014158251.01In StockOrion Fans51.0 @ 1
thumbzoomace4parts.comOA172SAPL-22-1TB53.5519Orion Fans53.55 @ 1
thumbzoomDigi-Key262095253.981In StockOrion Fans1.653.98 @ 1
Future Electronics369924657.132115Orion Fans57.132 @ 1
us.rs-online.com7010368158.041171Orion Fans58.04 @ 1
we-supply.comOA172SAPL-22-1TB58.911In StockOrion Fans58.91 @ 1
thumbzoomGalcoOA172SAPL-22-1TB-ORIN61.2123Orion1.761.2 @ 1
thumbzoomswatee.comOA172SAPL-22-1TB85.88146Orion Fans85.88 @ 1
thumbzoomRadwellOA172SAPL221TB101.512ORION FANS3.0101.5 @ 1
