Tritan 40BS28H X 1

mpn40BS28H X 1
brandname: TRITAN
manufacturername: TRITAN

TRITAN 40BS28H X 1 Finished Bore B-Hub Sprocket, 28 Teeth, 1/2" Pitch, 1" Finished Bore

TRITAN 40BS28H X 1 Finished Bore B-Hub Sprocket, 28 Teeth, 1/2" Pitch, 1" Finished Bore

zoom

Brand: Tritan
PartNumber: 40BS28H X 1
Model: 40BS28H X 1
PackageQuantity: 1
Binding: Misc.
Manufacturer: Bearings Ltd.
Label: Bearings Ltd.

Attributes

Key	Value
ANSI Sprocket Number	40
Bore Dia. (In.)	1
Bore Dia. - Sprockets	1 Inch
Bore Diameter	1 in
Bore Type	Finished Bore with Keyw.
Brand	Tritan
Chain Number	40
Color	Black Oxide
Country of Origin (subj.	China
Current Stock	47
Finish	Black Oxide
For Chain Number	40
For Chain Pitch	1/2 in
For Number of Strands	Single
For Use With	Roller Chain
Hub Dia.	3.75 in
Hub Dia. (In.)	3-3/4
Hub Diameter	3 3/4 in
Hub Projection	1 in
Hub Type	One Side
Includes	Standard Keyway and (2).
Industry Chain Pitch	1/2 in
Industry Chain Size	40
International Shipping	No
Item	Sprocket
Item - Roller Chain Spr.	Roller Chain Sprocket
Keyseat Size (In.)	1/4 x 1/8
Keyway	Yes
Keyway Depth	1/8 in
Keyway Size	1/4 in x 1/8 in
Keyway Width	1/4 in
Lead Time	Expected to ship in 1-2.
Length through Bore	1 in, 1.0"
Length through Bore (In.	1
Material	Steel
Material - Sprockets	Forged 1045 Alloy Steel
Maximum Bore Diameter	1 in
Mpn	40BS28H X 1
Number of Chain Rows	Single
Number of Set Screws	2
Number of Teeth	28
Number of Teeth - Sproc.	28
Outside Dia.	4.724 in
Outside Dia. (In.)	4.724
Outside Diameter	5 in
Pitch	1/2"
Pitch Dia.	0.5 in
Pitch Dia. (In.)	0.500
Pitch Diameter	4.466 in
Set Screw Dia. (In.)	5/16
Set Screw Hole Dia.	0.313 in
Set Screw Location	One Setscrew Over The K.
Set Screw Size	5/16 in
Setscrew Location	One Setscrew Over The K.
SKU	ZO-G0029499
Sprocket Bore Type	Fixed Bore
Sprocket Hub Type	B Hub Type
Standards	ANSI B29.1, BIS
SubCategory	Power Transmission
Teeth Heat Treatment	Hardened Teeth
Temp. Range (F)	-50 to +500? F
Tooth Width	0.284 in
Type	Finished Bore
UPC	888569094940
Width Across Tooth Sets	Not Applicable

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	Zoro	G0029499	30.4	1	In Stock		Tritan	2.68	30.4 @ 1
	simsupply.com	ZO-G0029499	43.08	1	47		Tritan		43.08 @ 1
	Grainger	36GC31	45.0	1	27	0	TRITAN		45.0 @ 1
	grainger.ca	WWG36GC31	46.80722894	1	In Stock		TRITAN	2.68	46.80722894 @ 1
	Raptor Supplies	AH6UDN	65.4878835	1	In Stock		TRITAN		65.4878835 @ 1
