- mpnA2240806-UNC8
- brandname: WALTER PROTOTYP
- manufacturername: WALTER PROTOTYP
Walter Tools A2240806-UNC8 Paradur HSS Machine Tap, TICN Finish, 0.168" Shank Diameter, 0.591" Cutting Length, 2-1/8" Overall Length, No. 8-32 Cutting Diameter
- Brand: Walter Tools
- PartNumber: A2240806-UNC8
- Model: 5348365
- Size: No. 8-32
- PackageQuantity: 1
- Binding: Misc.
- Manufacturer: Walter
- Label: Walter
Attributes
| Key | Value |
|---|
| 55% Thread Drill Size | 3.60 mm |
| 65% Thread Drill Size | 3.50 mm |
| 75% Thread Drill Size | 3.40mm |
| Catalog Page | N/A |
| Class of Fit | 3B |
| Coolant Fed | Non-Coolant Through |
| Country of Origin | Germany |
| Country of Origin (subj. | Germany |
| Cutting Direction - Mac. | Right Hand |
| Drill Bit Size | 0.1380 in |
| Extended Neck | Yes |
| Features | For Long Chipping Mater. |
| Helix Angle | 25 ?, 25 Degrees |
| Item | Spiral Flute Tap |
| Item? | 427M78 |
| List Number | A2240806 |
| Measurement System | Pipe |
| Mfr. Model? | A2240806-UNC8 |
| Number of Flutes | 3 |
| Number of Pieces | 1 |
| Overall Length | 54.00 mm, 2-3/16" |
| Pitch Diameter Limit | 3B |
| Primary Material Applic. | Nickel; Titanium, Nicke. |
| Primary Material Applic. | S |
| Secondary Material Appl. | Steel |
| Secondary Material Appl. | P |
| Series | Paradur Ni |
| Shank Dia. | 4.27 mm, 3/16" |
| Shank Length | 21.40 mm |
| Shank Type - Machining | Straight |
| Spiral Direction | Right Hand |
| Square Size | 3.33mm |
| Standards | ANSI B94.9 |
| Tap Chamfer | Plug, Modified Bottomin. |
| Tap Dimension Type | Inch |
| Tap Finish | TiCN |
| Tap Material | High Speed Steel |
| Tap Shank Standard | ANSI B94.9 |
| Tap Size | #8 |
| Tap Style | Spiral Flute |
| Tap Thread Size | #8-32 |
| Tap Thread Type | UNC |
| Thread Direction | Right Hand |
| Thread Length | 9/16", 15.00 mm |
| Thread Limit | H3; H4, H3, H4 |
| Thread Limit / Class of. | H3 / 3B, H4 / 3B, H3 / . |
| Thread Size | #8-32 |
| Thread Standard | UNC |
| Threads per Inch | 32 |
| UNSPSC | 27112806 |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
 | Zoro | G2560490 | 49.1 | 1 | In Stock | | Walter Prototyp | 0.01 | 49.1 @ 1 |
| Grainger | 427M78 | 59.4 | 1 | In Stock | | WALTER PROTOTYP | | 59.4 @ 1 |
