3M MNG18-250DMIK

mpnMNG18-250DMIK
brandname: 3-M
manufacturername: 3-M

3M SCOTCHLOK MALE DISCONNECT, FULLY NYLON INSULATED W/INSULATION GRIP MNG18-250DMIK, 22-18 AWG

3M SCOTCHLOK MALE DISCONNECT, FULLY NYLON INSULATED W/INSULATION GRIP MNG18-250DMIK, 22-18 AWG

zoom

Brand: 3M
PartNumber: MNG18-250DMIK
Model: MNG18-250DMIK
PackageQuantity: 1
Binding: Tools & Home Improvement
Manufacturer: 3M
Label: 3M

Attributes

Key	Value
3M Number	MNG18-250DMIK
Barrel Inside Dia.	0.065 in
Barrel Length	0.25 in
Barrel Length Type	Butted
Barrel Style:	Butted
Base Product Number	MNG18
Brand	3M
Category	Electrical Terminals, C.
Color	Red
Connection Material	Tin-Plated Copper
Connection Type	Crimp
Contact Finish	Tin
Contact Material	Copper, ETP
Country of Origin	USA
Country of Origin (subj.	United States
Fastener Orientation:	Male
Features	-
Gender	Male, Female
Inside Diameter	0.145 in
Insulation	Fully Insulated, Full
Insulation Color	Red
Insulation Diameter	0.145" (3.68mm)
Insulation Material	Nylon
Insulation Type	Nylon
Item	Male Disconnect
Length - Overall	0.950" (24.13mm)
Male Tab Width	0.25 in
Manufacturer	3M
Material	Nylon
Material:	Nylon
Max. Temp.	221 Degrees F
Max. Voltage	600 V
Maximum Wire Size	18 AWG
Mfr	3M
Minimum Conductor Leg D.	22 AWG
Minimum Wire Size	22 AWG
Mounting Type	Free Hanging (In-Line)
Number Of Terminals:	1000 per bulk box
Overall Diameter	0.3 in
Overall Length	0.95 in
Overall Width	0.44 in
Package	Bulk
Package Quantity	1000 per case
Pad Width	0.25 in
Pad Width:	0.250 Inch
Product Status	Active
Seam	Butted
Series	Scotchlok?
Standard:	UL and CSA
Standards	CSA Certified, RoHS Com.
Sub Brand:	Scotchlok
Tab Length	-
Tab Size	0.032 in x 0.250 in
Tab Thickness	0.032" (0.81mm)
Tab Width	0.250" (6.35mm), 0.250 .
Terminal Size:	22 - 18 AWG
Terminal Type	Disconnect, Standard
Termination	Crimp
Trade Name	Scotchlok
Type	Disconnect, Insulated
Type:	Disconnect
UNSPSC	39121432
UPC	054007023029
Width (W):	0.44 Inch
Wire Gauge	18-22 AWG
Wire Range	22 to 18 AWG

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	turtle.com	MMM MNG18-250DMIK	0.67	1	1000		3M		0.67 @ 1000
	Digi-Key	3865688	0.72526	1000	1000	26	3M		0.72526 @ 1000
	Platt.com	0063472	0.82	1	1000		3M		0.82 @ 1000
	Newark	02M6338	0.861	1000	1000		3M		0.861 @ 1000
	rshughes.com	054007-02302	560.0	1000	1000		3M		560.0 @ 1000
	gordonelectricsupply.com	MNG18-250DMIK	570.0	1	1000	455	3-M		570.0 @ 1000
	Dale-Electric	MNG18-250DMIK	628.32	1	1000		3M		628.32 @ 1000
	Zoro	G5543544	636.0	1	1000	26	3M	3.3	636.0 @ 1000
	Raptor Supplies	AB9KXT	1399.100976	1	1000		3M		1399.100976 @ 1000
