Martin 08A12

B00452TON8

Martin Roller Chain Sprocket, Reboreable, Type A Hub, Single Strand, 08B Chain Size, 12.7mm Pitch, 12 Teeth, 10mm Bore Dia., 55.02mm OD, 7.37mm Width

Martin Roller Chain Sprocket, Reboreable, Type A Hub, Single Strand, 08B Chain Size, 12.7mm Pitch, 12 Teeth, 10mm Bore Dia., 55.02mm OD, 7.37mm Widthzoom

Attributes

Key Value
Bore Diameter10 mm
bore diameter:10 mm
Bore TypeReboreable
bore type:Reboreable
caliper diameter:5.8 mm
chain / sprocket type:Metric Roller Chain
Chain Number08B
chain number & pitch:08B / 1/2 in
Chain Pitch12.7 mm
chain roller diameter:8.509 mm
chain roller width:0.29 mm
hardened teeth:Non-Hardened Teeth
Hub ConfigurationNo Hub
hub style:A
Length Through Bore0.209 in
length through bore:5 mm
manufacturer upc number:697950396835
MaterialSteel
material:Steel
maximum bore diameter:mm
number of hubs:0
number of strands acros.1
Number of Teeth12
Number Of Teeth12
number of teeth:12
Outer Diameter2.22185165257813 in
Outside Dia56.435 mm
outside diameter:56.4 mm
Pitch12.700 mm, 12.7 mm
Pitch Diameter1.93185165257813 in, 49.
pitch diameter:49.1 mm
pitch type:Single
storage dimension heigh.0.21 mm
storage dimension lengt.2.22 mm
storage dimension width:2.22 mm
surface treatment:Protective Coating
tooth thickness:7 mm
tooth width:5 mm
TypeStock Bore Sprockets
weight:0.18 lbs

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomindustrialzone.com08A1217.7112In StockMartin1.017.71 @ 12
us.rs-online.com7232593620.081In StockMartin Sprocket & Gear20.08 @ 1
thumbzoommotionindustries.com0020470824.031In StockMartin24.03 @ 1
thumbzoomPurvis08A1235.721In StockMartin35.72 @ 1
thumbzoomMRO Supply25820939.761In StockMartin Sprocket39.76 @ 1
