MICROCHIP PIC18F25K80-I/SO

B00LQQTSPU

MICROCHIP PIC18F25K80-I/SO MCU, 8BIT, PIC18, 64MHZ, SOIC-28

MICROCHIP PIC18F25K80-I/SO MCU, 8BIT, PIC18, 64MHZ, SOIC-28zoom

Attributes

Key Value
A/D Bit Size12 bit
A/D Channels Available8
ADC Resolution12 bit
Alternate Part No.579-PIC18F25K80-I/SO
ArchitectureC Compiler ; Harvard
Base Product NumberPIC18F25
BrandMicrochip Technology
CategoryIntegrated Circuits (IC.
Comparator Type2
ConnectivityECANbus, I?C, LINbus, S.
CorePIC
Core ProcessorPIC
Core Size8-Bit
CPU Speed16 MIPS
Data Bus Width8 bit
Data ConvertersA/D 8x12b
Data RAM Size1 kB
Data RAM TypeEEPROM
Data Rate16 MIPS
DescriptionIC MCU 8BIT 32KB FLASH .
Detailed DescriptionPIC PIC? XLP? 18K Micro.
Digi-Key Part NumberPIC18F25K80-I/SO-ND
DigiKey ProgrammableNot Verified
Dimensions17.90 x 7.50 x 2.35 mm
EEPROM Memory1024 B
EEPROM Size1K x 8
Family NamePIC18
Frequency64
Height0.093" (2.35mm)
Input Output24
InterfaceI2C/SPI/UART/USART
Interface TypeI2C, SPI, USART
Length0.704 in
ManufacturerMicrochip, Microchip Te.
Manufacturer Part No.PIC18F25K80-I/SO
Manufacturer Product Nu.PIC18F25K80-I/SO
Manufacturer Standard L.46 Weeks
Maximum Clock Frequency64 MHz
Maximum Number of CAN C.1
Maximum Number of Ether.0
Maximum Number of I2C C.1
Maximum Number of LIN C.1
Maximum Number of PCI C.0
Maximum Number of SPI C.1
Maximum Number of UART .2
Maximum Operating Tempe.+ 85 C, +85 ?C
Memory TypeFLASH
MfrMicrochip Technology
Minimum Operating Tempe.-40 ?C, - 40 C
Mounting StyleSMD/SMT
Mounting TypeSurface Mount
Number of ADCs8 x 12 bit
Number of Bits8
Number of I/O24
Number of I/Os24 I/O
Number of IO Ports24
Number of Pins28
Number of PWM Units1
Number of Timers5 Timer, 5
On-Chip ADCYes
Operating Supply Voltage1.8 V to 5.5 V
Operating Temperature-40?C ~ 85?C (TA)
Operating Voltage1.8 to 5 V
Oscillator TypeInternal
PackageTube
Package / Case28-SOIC (0.295", 7.50mm.
Package TypeSOIC
Package/CaseSOIC-28
PackagingTube
PeripheralsBrown-out Detect/Reset,.
Processor SeriesPIC18
Product Category8-bit Microcontrollers .
Product StatusActive
Program Memory Size32KB (16K x 16), 32 kB
Program Memory TypeFLASH
Programmable Memory32K Bytes
PWM Channels1 (ECCP), 4 (CCP)
RAM Size3.6K x 8, 3648 B
SeriesPIC? XLP? 18K, PIC18, P.
Speed64MHz, 64 MHz
Supplier Device Package28-SOIC
Supply Voltage - Max5.5 V
Supply Voltage - Min1.8 V
Temperature Operating R.-40 to +85 ?C
Temperature Range-40 to 125 C
Timer Resolution8, 16 bit
Timers2 x 8 bit, 3 x 16 bit
TypePIC
USB Channels1 x Device
Voltage - Supply (Vcc/V.1.8V ~ 5.5V
Voltage Range1.8-5.5 V
Width0 in

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
HotendaH23079522.6611672Microchip Technology2.66 @ 1
Onlinecomponents.comPIC18F25K80-I/SO2.821297MICROCHIP TECH.2.82 @ 1
Win SourcePIC18F25K80-I/SO2.934202000Microchip Technology2.934 @ 20
thumbzoomNewark75T79973.59112194MICROCHIP3.59 @ 1
thumbzoomDigi-Key26015193.62197Microchip Technology3.62 @ 1
thumbzoomTMEPIC18F25K80-I/SO3.79144MICROCHIP TECHNOLOGY3.79 @ 1
RS Delivers715-46185.052123Microchip5.052 @ 1
thumbzoomswatee.comPIC18F25K80-I/SO5.491748Microchip5.49 @ 1
us.rs-online.com7004754211.62723In StockMicrochip Technology Inc.11.62 @ 723
thumbzoomAmazonSCB07L46FVTW76.16123MICROCHIP TECHNOLOGY76.16 @ 1
AmazonTPB07L46FVTW81.761231Microchip Technology81.76 @ 1
