TE Connectivity / AMP 5-825440-0

mpn5-825440-0
brandname: TE Connectivity
manufacturername: TE Connectivity

TE CONNECTIVITY/AMP 5-825440-0 Header, 2ROW, 100WAY

Brand: TE Connectivity / AMP
PartNumber: 5-825440-0
PackageQuantity: 1
Manufacturer: TE CONNECTIVITY / AMP
Label: TE CONNECTIVITY / AMP

Attributes

Key	Value
Applications	-
Base Product Number	825440
Category	Connectors, Interconnec.
Color	Green, Black
Connection Material	Brass, Copper-Zinc
Connector Terminates To	Printed Circuit Board
Connector Type	Header
Contact Finish	Gold Plated
Contact Finish - Mating	Gold
Contact Finish - Post	Tin
Contact Finish Thicknes.	3.90?in (0.099?m)
Contact Finish Thicknes.	98.4?in (2.50?m)
Contact Length - Mating	0.264" (6.70mm)
Contact Length - Post	0.126" (3.20mm)
Contact Material	Brass
Contact Plating Thickne.	0.7 ?m
Contact Shape	Square
Contact Type	Male Pin, Pin
Current Rating (Amps)	-
Description	CONN HEADER VERT 100POS.
Detailed Description	Connector Header Throug.
Digi-Key Part Number	A106723-ND
Fastening Type	Push-Pull
Features	With Strain Relief; Sid.
Flammability Rating	UL 94 V-0
Hole Center to Center	2.54 mm
Ingress Protection	-
Insulation Color	Green
Insulation Height	0.110" (2.79mm)
Insulation Material	Polybutylene Terephthal.
Item	PCB Mount Header
Manufacturer	TE Connectivity AMP Con.
Manufacturer Product Nu.	5-825440-0
Manufacturer Standard L.	25 Weeks
Mated Stacking Heights	-
Material	Glass-Filled PBT
Material Flammability R.	UL94 V-0
Max. Temp.	105?C
Mfr	TE Connectivity AMP Con.
Mounting Type	Through Hole
Number of Contacts	100
Number of Positions	100
Number of Positions Loa.	All
Number of Rows	2
Operating Temperature	-65?C ~ 105?C
Overall Contact Length	0.500" (12.70mm)
Package	Bulk
Package Quantity	1
Pitch - Mating	0.100" (2.54mm)
Product Status	Active
Row Spacing - Mating	0.100" (2.54mm)
Series	AMPMODU Mod II
Shrouding	Unshrouded
Style	Board to Board or Cable
Terminal Finish	Tin Plated
Terminal Type	Through Hole
Termination	Solder
Type	Breakaway
Voltage Rating	-

All Prices

Seller	Supplier SKU	Min Price	MOQ	In Stock	Brand	Preferred Tier
us.rs-online.com	71918569	9.2	1560	10	TE Connectivity	9.2 @ 1560
Newark	98K9593	10.03	1	1517	AMP - TE CONNECTIVITY	10.03 @ 10
Hotenda	H1302636	10.38	1	10	TE Connectivity AMP Connectors	10.38 @ 10
Digi-Key	2276072	11.007	1	1560	TE Connectivity AMP Connectors	11.007 @ 10
TME	5-825440-0	11.72	1	14	TE Connectivity	11.72 @ 10
RS Delivers	388-8285P	12.8268	1	70	TE Connectivity	12.8268 @ 10
Zoro	G600938847	86.5	1	10	Te Connectivity	86.5 @ 10
