MEAN WELL HLG-120H-C500A

B073ZBXFKY

MW Mean Well HLG-120H-C500A 300V 500mA 150W Single Output Switching LED Power Supply with PFC

MW Mean Well HLG-120H-C500A 300V 500mA 150W Single Output Switching LED Power Supply with PFCzoom

Attributes

Key Value
AC inrush current (max.)Cold start, 60A at 230V.
Approval AgencyCB, CCC, CE, cURus, ENE.
ASINLED
Base Product NumberHLG-120H
Batteries Included?No
Batteries Required?No
CategoryPower Supplies - Extern.
ColorWhite
ConfigurationSealed
Connection InputUL rated, SJTW 18AWGx3C.
Current - Output (Max)500mA
Current adjustment range50%~100%
DescriptionLED DRVR CC AC/DC 150-3.
Detailed Description500mA 150 ~ 300V Consta.
Digi-Key Part Number1866-2351-ND
DigiKey ProgrammableNot Verified
Dimension (LxWxH) (mm)220x 68x 38.8
Dimensions220 x 68 x 38.8mm
DimmableConstant current level .
Dimming-
Efficiency94%
Family NameHLG Family
FeaturesOTP, OVP, SCP
FinishCopper
Industry Aliasesnew
Input Voltage110 VAC ; 115 VAC ; 120.
Input Voltage Range100-305 VAC
Is Discontinued By Manu.No
Isolation ResistanceI/P - O/P, I/P-FG, O/P-.
ManufacturerMEAN WELL USA Inc.
Manufacturer Product Nu.HLG-120H-C500A
Manufacturer Standard L.14 Weeks
MaterialMetal
MfrMEAN WELL USA Inc.
Mounting TypePanel Mount, Chassis Mo.
MTBF191.1K hrs min. MIL-HDB.
Number of Outputs1
Operating Temperature-40?C ~ 90?C
OperationPFC
Output Current0.5 A
Output Power1010 W
Output Rated Current500mA
Output VoltageC.C Variable, 300 VDC
Over Temperature85?C?10?C (RTH2)
Over Voltage335 ~355V
Over voltage protection110%~140% rated output .
PackageBox
Part NumberHLG-120H-C500A
Power (Watts)150 W
Primary TypeAC-DC
Product StatusActive
RatingsIP65
Safety standardsUL8750, TUV EN61347-1, .
SeriesHLG-120H-C (150W), HLG-.
Size / Dimension7.72" L x 2.68" W x 1.5.
Special FeaturesConstant Current Operat.
Storage Temp., Humidity-40 ~ +80?C, 10 ~ 95% RH
Temp. Coefficient?0.03%/?C (0 ~ 50?C)
Termination StyleWire Leads
TopologyAC DC Converter
TypeConstant Current, LED D.
Vibration10 ~ 500Hz, 5G 12min. /.
Voltage - Input (Max)305VAC
Voltage - Input (Min)90VAC
Voltage - Isolation3.75 kV
Voltage - Output150 ~ 300V
Wattage120
Withstand VoltageI/P - O/P : 3.75KVAC---.
Withstand voltageI/P-O/P: 3.75kVAC, I/P-.
Working Humidity10 ~ 95% RH non-condens.
Working Temp.-25 ~ +70?C (Refer to ".

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Sager ElectronicsHLG-120H-C500-A45.2116Mean Well45.2 @ 1
thumbzoompowersupplymall.comHLG-120H-C500A49.3112Mean Well49.31 @ 1
Mouser709-HLG120H-C500A51.0317Mean Well51.03 @ 1
Onlinecomponents.comHLG-120H-C500A51.29142Mean Well51.29 @ 1
thumbzoompeaktopeakpower.comHLG-120H-C500A56.01In StockMean Well56.0 @ 1
us.rs-online.com7038747463.61In StockMEAN WELL63.6 @ 1
thumbzoomNewark64AJ447564.8611MEAN WELL64.86 @ 1
AmazonTPB0137I9YW665.061In Stock2MEAN WELL65.06 @ 1
AmazonUNKB0137I9YW665.061In StockMEAN WELL65.06 @ 1
thumbzoomDigi-Key770390765.772150MEAN WELL USA Inc.65.772 @ 1
thumbzoomTMEHLG-120H-C500A66.25110MEAN WELL66.25 @ 1
thumbzoomAmazonSCB073ZBXFKY69.531In StockMEAN WELL69.53 @ 1
electricautomationnetwork.comHLG-120H-C500A73.171In StockMEANWELL73.17 @ 1
