39-29-6248

B005T7Z1QM

Headers & Wire Housings 24 CKT VERT HEADER (1 piece)

Headers & Wire Housings 24 CKT VERT HEADER (1 piece)zoom

Attributes

Key Value
ApplicationsGeneral Purpose, Indust.
Base Product Number003929
CategoryConnectors, Interconnec.
ColorNatural
Connector TypeHeader
Contact Finish - MatingGold
Contact Finish - PostTin
Contact Finish Thicknes.30.0?in (0.76?m)
Contact Finish Thicknes.100.0?in (2.54?m)
Contact Length - Mating-
Contact Length - Post0.138" (3.50mm)
Contact MaterialBrass
Contact ShapeSquare
Contact TypeMale Pin
Current Rating (Amps)-
DescriptionCONN HEADER VERT 24POS .
Detailed DescriptionConnector Header Throug.
Digi-Key Part NumberWM23831-ND
Fastening TypeLocking Ramp
Features-
Ingress Protection-
Insulation ColorNatural
Insulation Height0.504" (12.80mm)
Insulation MaterialPolyamide (PA66), Nylon.
ManufacturerMolex
Manufacturer Product Nu.0039296248
Manufacturer Standard L.11 Weeks
Mated Stacking Heights-
Material Flammability R.UL94 V-0
MfrMolex
Mounting TypeThrough Hole
Number of Positions24
Number of Positions Loa.All
Number of Rows2
Operating Temperature-
Overall Contact Length-
PackageBulk
Part StatusActive
Pitch - Mating0.165" (4.20mm)
Product StatusActive
Row Spacing - Mating0.165" (4.20mm)
SeriesMini-Fit Jr 5566
ShroudingShrouded - 4 Wall
StyleBoard to Cable/Wire
TerminationSolder
Voltage Rating-

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
WaldomMOLEX 39-29-62485.361074MOLEX5.36 @ 10
Onlinecomponents.com39-29-62485.55117MOLEX / WALDOM5.55 @ 5
Power and Signal Group00392962485.60796005Molex5.6079 @ 600
thumbzoomjensentools.com101884507.15174Molex7.15 @ 5
thumbzoomNEP Electronics39-29-62487.44121074Molex7.4412 @ 10
thumbzoomNewark01AH11238.3715MOLEX8.37 @ 5
thumbzoomDigi-Key93031910.5814105Molex10.58 @ 5
AmazonTPB005T7Z1QM13.78152Molex13.78 @ 5
thumbzoomRadwell39-29-624816.015MOLEX16.0 @ 5
thumbzoomZoroG70041703782.515Molex82.5 @ 5
