Molex 39514-0002

B00NSD0UFQ

Molex Terminal Block,Cable Mount,Plug,2 Contacts,SKT,Locking - 39514-0002

Molex Terminal Block,Cable Mount,Plug,2 Contacts,SKT,Locking - 39514-0002zoom

Attributes

Key Value
Base Product Number039514
CategoryConnectors, Interconnec.
Circuits (Loaded)2
ColorBlack
Contact MaterialPhosphor Bronze
Contact Mating FinishTin
Contact Tail Length-
Current - IEC-
Current - Maximum per C.8.0A
Current - UL8 A
DescriptionTERM BLOCK PLUG 2POS ST.
Detailed Description2 Position Terminal Blo.
Digi-Key Part Number0395140002-ND
Entry AngleVertical
FeaturesMating Flange
Header Orientation-
Housing MaterialPolyamide (PA66), Nylon.
Ingress Protection-
Insulation Height-
Lock to Mating PartYes
ManufacturerMolex
Manufacturer Product Nu.0395140002
Manufacturer Standard L.12 Weeks
Material Flammability R.UL94 V-0
MfrMolex
Mounting TypeFree Hanging (In-Line)
Number of Levels1
Number of Positions2
Number of Rows1
Operating Temperature-40?C ~ 115?C
OrientationHorizontal
PackageBulk
Package Quantity1
Panel MountNo
Pitch0.150" (3.81mm)
Pitch - Mating Interface3.81mm
Pitch - Termination Int.3.81mm
Plug Wire Entry180?
Polarized to Mating PartYes
Positions Per Level2
Product StatusActive
Screw SizeM2
SeriesEurostyle ESE 39514
StackableNo
Temperature Range - Ope.-40? to +105?C
Termination StyleScrew - Rising Cage Cla.
Torque - Screw0.23 Nm (2.0 Lb-In)
TypePlug, Female Sockets
ULE48521
Voltage - Maximum300V
Voltage - UL300 V
Wire Gauge or Range - A.16-30 AWG
Wire Gauge or Range - m.-
Wire Size AWG16, 18, 20, 22, 24
Wire Size mm?0.20-1.31
Wire Strip Length-

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Onlinecomponents.com39514-00020.3791241MOLEX / WALDOM0.379 @ 1
thumbzoomDigi-Key27365160.4058765400246Molex0.405876 @ 5400
Newark59R36620.4285400233MOLEX0.428 @ 5400
thumbzoomjensentools.com101887400.431233Molex0.43 @ 1
thumbzoomRadwell39514-00021.4400233MOLEX1.4 @ 400
thumbzoomZoroG9059191144536.01233Molex4536.0 @ 1
