- mpnEE511B
- brandname: US Motors
- manufacturername: US Motors
U.S. Motors US Motors Pump, 1 HP, 3-Phase, 3450 RPM Motor, EE511B
- Brand: U.S. Motors
- PartNumber: EE511B
- Manufacturer: U.S. Motors
- Label: U.S. Motors
Attributes
| Key | Value |
|---|
| Composition | Rolled Steel |
| Construction | Rolled Steel |
| Drive End Flange Type | C-Face |
| Duty | CONT |
| Enclosure | Open Drip Proof, Open |
| Estimated Weight | 28.60 |
| Family Series | US Motors Motors |
| FL Amps | 3.6-3.8/1.9 |
| Frame | 56C |
| Frequency | 60 Hz |
| Gross Weight | 26 lbs |
| Hertz | 50, 60 |
| Horsepower | 1 HP |
| HP | 1, 1 HP |
| Hz | 60 & 50 Hz |
| Ins. Class | B |
| Item | Motor,1HP,3450,2850RPM,. |
| Item Number | EE511B |
| Kilowatts | 0.8 kW |
| Manufacturer | US Motors (Nidec), US M. |
| Manufacturer Part Number | EE511B |
| Model Number | P055DEB1490015J |
| Motor Bearings | 62036203 |
| Motor Mounting Type | C-FACE/BASE |
| Motor Thermal Protection | NONE |
| Mounting | Foot Mount |
| Mounting Type | C-Face, Rigid |
| NEMA Frame | 56C |
| Net Weight | 0 lbs |
| Nominal Voltage | 208 VAC, 240 VAC, 380 V. |
| Number of Poles | 2 |
| Number of Speeds | 1 |
| Overload Protection | NONE |
| Package Quantity | 1 |
| Part Number | EE511B |
| Phase | 3, 3 ph |
| Product Type | General Purpose |
| RPM | 3,450 RPM |
| RPM Range | 3450 & 2850 RPM |
| Speed (RPM) | 3450 |
| Voltage | 190V, 230V, 380V, 460V,. |
| Voltage (AC) | 190 VAC, 208-230 VAC, 3. |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
 | motorsandcontrol.com | EE511B | 395.4 | 1 | In Stock | | US Motors (Nidec) | 28.6 | 395.4 @ 1 |
 | Zoro | G0919281 | 395.99 | 1 | In Stock | | U.S. Motors | 26.0 | 395.99 @ 1 |
 | Global Industrial | WBB466610 | 407.95 | 1 | In Stock | 17 | US Motors | | 407.95 @ 1 |
 | Guardian | 53653937 | 450.74 | 1 | In Stock | | US Motors | | 450.74 @ 1 |
 | National Supply Network | B466610 | 457.64 | 1 | In Stock | | US MOTORS | | 457.64 @ 1 |
 | Galco | EE511B-USM | 465.4 | 1 | In Stock | | US Motors | 26.0 | 465.4 @ 1 |
 | bscsource.com | EE511B | 493.69 | 1 | In Stock | | US Motors | | 493.69 @ 1 |
| motionindustries.com | 04385258 | 595.67 | 1 | In Stock | | US Motors (Nidec) | | 595.67 @ 1 |
