TB Woods P4820M115

B004LB657G

TB Woods P4820M115 Synchronous Plus Sprocket, J Bushing, 48 Teeth, 20 mm Tooth Pitch, 20M Section, 115 mm Belt Width, 11.861" OD

TB Woods P4820M115 Synchronous Plus Sprocket, J Bushing, 48 Teeth, 20 mm Tooth Pitch, 20M Section, 115 mm Belt Width, 11.861" ODzoom

Attributes

Key Value
Belt width115 mm
Bore typeQuick disconnect bushing
BushingJ
Bushing bore range1 7/16 - 4 1/2
Dimension4.5
Face width5.38
Flanges2
Groove profile20M
Hub diameter6.5
Hub length3.19
Hub location1.19
I.D.12.13
Inertia WR2 (lbs ft2)12.2
Inertia WR?544
Inside hub projection0
Material typeCast iron
Number of grooves48
Number of hubs0
Number of teeth48
O.D.12.52
O.D. (in)11.861
Outside hub projection0
Pitch20
Pitch diameter12.03
Rim face5.375
RPM upper limit2110
Tooth pitch20

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
AmazonTPB078Y6JNTJ1700.031In Stock10TB Woods1700.03 @ 1
thumbzoomMRO Supply3514401918.01In StockTB Woods1918.0 @ 1
