Dayton 4M077

B000TK9ESU

C-Frame Motor, Shaded Pole, 2-1/4 in. L

C-Frame Motor, Shaded Pole, 2-1/4 in. Lzoom

Attributes

Key Value
Amps0.37
BearingsBall
Capacitor RequiredNo
Cord Length12"
Cross Reference4M068
Enclosure TypeOAO (Open Air Over)
FrameC-Frame, Non-Standard
Full Load Amps0.37
HP1/250
Hz60
Ins. ClassB
Insulation ClassB
ItemC-Frame Motor
Length Less Shaft1-5/8"
Max. Ambient Temp.40 Degrees C
Maximum Ambient Tempera.40? C
Motor ApplicationHVAC/R
Motor BearingsBall
Motor DesignShaded Pole
Motor Enclosure DesignOpen Air-Over
Motor Mounting PositionAll Angle
Motor Mounting TypeStud
Motor Service Factor1.00
Motor Shaft RotationCWSE
Motor Shell Length1-5/8"
Motor Sub ApplicationDirect Drive Fan/Blower
Motor Thermal ProtectionImpedance
MountingStud
Mounting HolesOpposite Shaft End
Mounting Stud LocationShaft End
Nameplate RPM3,000
No. of Speeds1
Number of Shafts1
Number of Speeds1
O.C. Mounting1-7/8"
Phase1
Product TypeShaded Pole
RotationCW Shaft End
RPM3000
Service Factor (SF)1.00
Shaft Dia.3/16"
Shaft Diameter3/16"
Shaft Length2", 2-1/4"
Ship Weight2 lbs.
Stack Size1/2"
StandardsUL Recognized (E37403/E.
Stud Quantity2
Stud Size#8-32
Thermal ProtectionImpedance
Usable @ 200VNo
Usable @ 208VNo
Voltage120
Volts115

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
grainger.caWWG4M07733.13304391In StockDAYTON1.16833.1330439 @ 1
thumbzoomRaptor SuppliesAD8TDY56.2027051In StockDAYTON56.202705 @ 1
thumbzoomemotorpro.com4M07779.221In StockDayton2.079.22 @ 1
