SCHNEIDER ELECTRIC 9001K3L38LGGH13 Pushbutton 600-Vac 10-Amp 30-Mm T-K Electrical Box

SCHNEIDER ELECTRIC 9001K3L38LGGH13 Pushbutton 600-Vac 10-Amp 30-Mm T-K Electrical Boxzoom

Attributes

Key Value
[Icm] Rated Short-Circu.12 kA 600 V AC-15, 7200.
[Ie] Rated Operational .0.55 A 125 V, DC-13, A6.
[Ith] Conventional Free.10 A
[Ui] Rated Insulation V.250 V 3)IEC 60947-1
[Uimp] Rated Impulse Wi.2.5 kV IEC 60947-1
[Us] Rated Supply Volta.120 V, 120 V AC/DC
Actionstandard, Momentary
Actuatorspring return;Green flu.
Actuator TypeRound, Button, Flush
Ambient Air Temperature.-25-70 ?C
Ambient Air Temperature.-40-70 ?C
Amperage Rating10
Basic MaterialMetal
BezelChrome Plated Zinc Die .
Bezel MaterialMetal
BrandSchneider Electric
Bulb BaseBA 9s
Cad Overall Depth106 mm
Cad Overall Height42 mm
Cad Overall Width54 mm
California Proposition .Lead and lead compounds.
Cap/Operator Or Lens Co.Green
Catalog Number9001K3L38LGGH13
CategorySwitches
China Rohs RegulationX
CircuitSPDT
Circularity ProfileN/A
ColorGreen
Color - Actuator/CapGreen
ColourGreen
Connectionscrew clamp terminals 1.
Connections - Terminalsscrew clamp terminals 1.
Contact Configuration1 C/O
Contact Form1NO/1NC
Contact Operationstandard
Contact Rating10A @ 600V AC, 10 A @ 6.
Contact Type1NO/1NC
Contacts Materialsilver alloy contacts
Contacts Type And Compo.1 C/O
Country of OriginMexico
Current Rating (Amps)550mA (DC)
Current Stock9
DescriptionPUSH BUTTON 600VAC 10A .
Detailed DescriptionPushbutton Switch SPDT .
Device Presentationcomplete product
Device Short Name9001K
Digi-Key Part Number4008-9001K3L38LGGH13-ND
Electrical Life-
EnclosureNEMA 1/2/3/3R/4/6/12/13
Environmental ConditionsWATER TIGHT, DUST TIGHT.
Environmental DisclosureENVPEP121006EN
Eu Rohs DirectivePro-active compliance (.
Features-
GTIN00785901725787
Head MaterialMetal
Illumination Type, ColorLED, Green
Illumination Voltage (N.120 VAC/DC
IndicatorGreen
Ingress ProtectionIP66 - Dust Tight, Wate.
Insulation250 V 3)IEC 60947-1
International ShippingNo
Ip Degree Of ProtectionIP66 IEC 60529
IP Rating66
ItemIlluminated Push Button
Item Typeilluminated push-button
Lamp Module TypeFull Voltage
Lamp Module Voltage120V AC
Lamp TypeLed
Lamp Voltage120V AC
Lead TimeExpected to ship in 1-2.
Light Block Supplydirect
Light SourceLed
Light Source ColourGreen
Made in USANo
ManufacturerSchneider Electric
Manufacturer Product Nu.9001K3L38LGGH13
Manufacturer Standard L.1 Weeks
MaterialMetal
Mechanical Durability5000000 cycles
Mechanical Life5,000,000 Cycles
Mercury FreeYes
MfrSchneider Electric
MountingPanel Mount
Mounting Diameter30 mm
Mounting TypePanel Mount, Front
Mpn9001K3L38LGGH13
NEMA Contact Rating Des.A600/Q600
Nema Degree Of Protecti.NEMA 1 || NEMA 12 || NE.
NEMA Rating1, 12, 13, 2, 3, 3R, 4,.
Net Weight0.175 kg
Number of Operators1
Operating Positionany position
Operating Temperature-25?C ~ 70?C, -25-70 A .
Operator Additional Inf.metal guard
Operator Profilegreen flush, unmarked, .
Overvoltage Categoryclass II IEC 61140
PackageBox
Panel Cutout DimensionsCircular - 30.00mm Dia
Positive Openingwithout
Product CertificationsUL 508 || NEMA
Product Or Component Ty.illuminated push-button
Product StatusActive
Protective TreatmentTC
Range Of ProductHarmony 9001K
Rated Breaking Capacity1.2 kA 600 V AC-15, 720.
Reach RegulationReference contains Subs.
Replacement LampMfr. No. 25501-010-27
Rohs Exemption Informat.Yes
SeriesHarmony 9001K
Shape Of Screw Headcross slotted
Shape Of Signaling Unit.octagonal
Shock Resistance50 gn IEC 60068-2-27
Short-Circuit Protection10 A cartridge fuse IEC.
Size30 mm, 1.18
SKUZO-G2474832
Special FeaturesEXTENDED METALLIC GUARD
StandardUL FILE NUMBER E42259 C.
StandardsIEC 60947-1 || JIS C 45.
SubCategoryElectrical
Sustainable Offer StatusGreen Premium product
Switch FunctionOn-On
Terminal ConnectionPressure Plate
Terminals Description I.(13-14-11-12)OF
Termination StyleScrew Terminal
Tightening Torque0.8-0.8 N.m IEC 60947-1
TypeStandard, Illuminated
Type Of Operatorspring return
Type of OperatorRound Extended Guarded .
UPC785901725787
UPC Code785901725787
Vibration Resistance7 gn 2-500 Hz)IEC 60068.
Voltage Rating120 V AC/DC
Voltage Rating - DC125 V
Warranty18 months
Warranty DescriptionContractual Warranty:18.
WeeeThe product must be dis.
