TE Raychem V23154C721F105

B07NQRWSWT

TE Raychem Connector

TE Raychem Connectorzoom

Attributes

Key Value
Base Product Number9-1393806
Body dimensions30x30x19mm
CategoryRelays
Coil Current27 mA
Coil Insulation-
Coil power consumption647mW
Coil Resistance890 Ohms
Coil resistance890?
Coil TypeNon Latching
Coil Voltage24VDC
Coil voltage max.40V DC
Coil voltage min.11V DC
Contact current max.5A
Contact FormDPST-NO (2 Form A)
Contact materialsilver alloy
Contact MaterialSilver (Ag)
Contact platinggold-plated
Contact Rating (Current)5 A
Contacts configurationDPST-NO
Country of Origin (subj.Mexico
Features-
Leadsfor soldering
ManufacturerTE Connectivity
MfrTE Connectivity Potter .
Mountingsocket
Mounting TypeSocketable
Must Operate Voltage11 VDC
Must Release Voltage-
Operate Time7.5 ms
Operating Temperature-40?C ~ 70?C
Operating temperature-40...70?C
PackageBulk
Product StatusActive
Rated coil voltage24V DC
Relay seriesCradle N
Relay TypeGeneral Purpose
Relay variantminiature
Release Time3 ms
Seal Rating-
SeriesV23154, AXICOM
Switching Voltage125VAC, 150VDC - Max
Termination StylePlug In
Type of relayelectromagnetic

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Digi-Key205384095.9650In StockTE Connectivity Potter & Brumfield Relays95.96 @ 50
Newark42AJ7404132.3450In StockAMP - TE CONNECTIVITY132.34 @ 50
thumbzoomZoroG701034806138.950In StockTe Connectivity138.9 @ 50
