WIDIA WMTCL2020K113

mpnWMTCL2020K113
brandname: Widia
manufacturername: Widia

WIDIA WMTCL2020K113 WMT Integral Tool Holder, 1 Seat Size, 26mm Max Bore Dia, 20mm Square Shank, Left Hand, 31.75mm Max Cut Depth

WIDIA WMTCL2020K113 WMT Integral Tool Holder, 1 Seat Size, 26mm Max Bore Dia, 20mm Square Shank, Left Hand, 31.75mm Max Cut Depth

zoom

Brand: WIDIA
PartNumber: WMTCL2020K113
Model: WMTCL2020K113
PackageQuantity: 1
Binding: Misc.
Manufacturer: WIDIA Products Group
Label: WIDIA Products Group

Attributes

Key	Value
ANSI Code	WMTCL2020K113
Center to Cutting Tip	20.00mm
Coolant Fed	Non-Coolant Through
Country of Origin (subj.	United States
Cutting Application	Cut-Off, Grooving, Prof.
Cutting Direction	Left Hand
Head Length	24.19mm
Insert Holding Type	Clamp
Insert Size	1
Insert Style	WMTC015N00CM08
ISO Number	WMTCL2020K113
Item	Indexable Thread Turnin.
Measurement System	Metric
Overall Length	125.00mm
Shank Height	20.00mm
Shank Length	100.81mm
Shank Material	High Speed Steel
Shank Shape	Square
Shank Width	19.86mm
Toolholder Style	WMT

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	Zoro	G3748541	128.48	1	In Stock	26	Widia	0.77	128.48 @ 1
