Burndy YA36L2NT38FX

B00CBNC3MM

Burndy YA36L2NT38FX Two Hole Hylug Flex Conductor Standard Barrel Narrow Tongue, 444.4 kcmil, 1100/24 450 Flex Conductor, 4.24" Length, 3/8" Stud Hole Size, 1.63" Tongue Width (Pack of 25)

Burndy YA36L2NT38FX Two Hole Hylug Flex Conductor Standard Barrel Narrow Tongue, 444.4 kcmil, 1100/24 450 Flex Conductor, 4.24" Length, 3/8" Stud Hole Size, 1.63" Tongue Width (Pack of 25)zoom

Attributes

Key Value
ApplicationWire Termination
ApprovalsCSA, UL
BrandBurndy-US, a Hubbell af.
Catalog NumberYA36L2NT38FX
Certification - CSA App.Yes
Certification - cULusNo
Certification - UL Reco.No
Color CodeBrown
Conductor - Copper DLO .444.4 (1100/#24) DLO
Conductor - Copper DLO .444.4 (1100/#24) DLO
Conductor - Copper Flex.450 kcmil
Conductor - Copper Flex.450 kcmil
Conductor - Copper Flex.450 kcmil
Conductor - Copper Flex.450 kcmil
Conductor - Copper Flex.450 kcmil
Conductor - Copper Flex.450 kcmil
Conductor - Copper Flex.450 kcmil
Conductor - Copper Flex.450 kcmil
Conductor - Copper Flex.450 kcmil
Conductor - Copper Flex.450 kcmil
Connector TypeTerminal
Country of OriginUnited States
Die Index20
Dimension - B Length fr.1-3/8 in
Dimension - B Length in.1.38 in
Dimension - Bolt Hole S.0.41 in
Dimension - Bolt Size f.3/8
Dimension - D inch2.03 in
Dimension - L Length Ov.108 mm
Dimension - Length Over.4.24 in
Dimension - N inch0.50 in
Dimension - Outside Dia.1.19 in
Dimension - Pad Width i.1.63 in
Dimension - Strip Lengt.1-7/16
Dimension - Stud Size i.3/8
Dimension - Z inch0.53 in
Family SeriesBurndy Terminals
Feature - Barrel TypeStandard
Gross Weight0.0338 lbs
Item NumberYA36L2NT38FX
Item TypeYA-L-2TC-FX, Standard B.
Made in USAYes
ManufacturerBurndy, Burndy, a Hubbe.
Manufacturer Part NumberYA36L2NT38FX
MaterialCopper
Material/CompositionCopper
Max Conductor Range444.4 kcmil
Min Conductor Range444.4 kcmil
Net Weight0 lbs
Number of Holes2
Physical Attribute - Nu.2
Physical Attribute - To.Straight
PlatedY
Plating TypeTin - Electro Plated
Rating - KVA35 kV
Rating - Minimum Voltage600
Special FeaturesFeatures: Compression N.
StandardUL 486A-486B
Standards - RoHS Compli.CM
Stud Size3/8 "
Sub BrandTERMINALS, HYLUG
Trade NameHYLUG?
UL ListedYes
UPC781810067758
Voltage - Maximum35000
Voltage Rating35

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomusmegastore.comYA36L2NT38FX63.82125Burndy63.82 @ 25
thumbzoomGalcoYA36L2NT38FX-BURN97.572525Burndy0.033897.57 @ 25
kirbyrisk.com2505761145.71125Burndy145.71 @ 25
thumbzoomcrescentelectric.com812705147.01125Burndy-US, a Hubbell affiliate147.01 @ 25
AmazonB00CBNC3MM1540.24125Burndy1540.24 @ 25
thumbzoomgordonelectricsupply.comYA36L2NT38FX1865.5125BURNDY1865.5 @ 25
