ANALOG DEVICES LTC2631CTS8-LZ12#TRMPBF

B07RC2D7RF

LTC2631CTS8-LZ12#TRMPBF, DAC 1-CH 12-bit 8-Pin TSOT-23 T/R (25 Items)

LTC2631CTS8-LZ12#TRMPBF, DAC 1-CH 12-bit 8-Pin TSOT-23 T/R (25 Items)zoom

Attributes

Key Value
Architecture-
Base Product NumberLTC2631
BrandAnalog Devices
CategoryIntegrated Circuits (IC.
Data InterfaceI?C
DescriptionIC DAC 12BIT V-OUT TSOT.
Detailed Description12 Bit Digital to Analo.
Differential OutputNo
Digi-Key Part NumberLTC2631CTS8-LZ12#TRMPBF.
DigiKey ProgrammableNot Verified
Digital Interface TypeSerial (I2C)
DimensionsDimensions
Full Scale ErrorFull Scale Error
Height0.9mm
INL/DNL (LSB)?1, ?1 (Max)
Integral Nonlinearity E.?1LSB
Length2.9mm
ManufacturerAnalog Devices Inc.
Manufacturer Product Nu.LTC2631CTS8-LZ12#TRMPBF
Manufacturer Standard L.13 Weeks
Maximum Operating Tempe.+70 ?C
Maximum Settling TimeMaximum Settling Time
MfrAnalog Devices Inc.
Minimum Operating Tempe.0 ?C
Mounting TypeSurface Mount
Number of Bits12
Number of D/A Converters1
Number of DAC ChannelsNumber of DAC Channels
Operating Temperature0?C ~ 70?C
Output TypeVoltage - Buffered
PackageTape & Reel (TR)
Package / CaseSOT-23-8 Thin, TSOT-23-8
Package TypeTSOT-23
Pin Count8
Power Supply TypeSingle
Product StatusActive
Reference TypeExternal, Internal
Resolution12 bit
Series-
Settling Time4.1?s (Typ)
StockStock
Supplier Device PackageTSOT-23-8
Typical Single Supply V.Maximum of 5.5 V
Voltage - Supply, Analog2.7V ~ 5.5V
Voltage - Supply, Digit.2.7V ~ 5.5V
Voltage ReferenceExternal, Internal
Width1.75mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomRS Delivers151-33462.8044250Analog Devices2.8044 @ 50
thumbzoomNewark80AK48424.231953ANALOG DEVICES4.23 @ 50
thumbzoomDigi-Key19313374.622411168Analog Devices Inc.4.6224 @ 50
