- mpn22057028
- brandname: MOLEX
- manufacturername: MOLEX
OPA343NA/3K IC OPAMP GP R-R 5.5MHZ SOT23-5 RoHS
- PartNumber: 22057028
- Model: 22057028
- PackageQuantity: 1
- Manufacturer: Molex
- Label: Molex
Attributes
| Key | Value |
|---|
| <a target="_blank" href. | //www.ibselectronics.co. |
| Alternate Mfr Part Numb. | A-7395-2B |
| Alternate Part No. | 538-22-05-7028 |
| Application | Signal ; Wire-to-Board |
| Applications | Automotive, General Pur. |
| Base Product Number | 002205 |
| Brand | Molex |
| Category | Connectors, Interconnec. |
| Circuits (Loaded) | 2 |
| Circuits (maximum) | 2 |
| Color | White, Natural |
| Color - Resin | Natural (White) |
| Connector Type | Header |
| Contact Finish - Mating | Tin |
| Contact Finish - Post | Tin |
| Contact Finish Thicknes. | 60.0?in (1.52?m) |
| Contact Finish Thicknes. | 60.0?in (1.52?m) |
| Contact Length - Mating | 0.264" (6.70mm) |
| Contact Length - Post | 0.150" (3.81mm) |
| Contact Material | Brass |
| Contact Plating | Tin, 4 A |
| Contact Shape | Square |
| Contact Type | Male Pin |
| CSA | LR19980 |
| Current - Maximum per C. | 4.0A |
| Current Rating | 4 A |
| Current Rating (Amps) | - |
| Description | CONN HEADER R/A 2POS 2.. |
| Detailed Description | Connector Header Throug. |
| Digi-Key Part Number | WM2784-ND |
| Durability (mating cycl. | 25 |
| Duration at Max. Proces. | 5 |
| Factory Pack Quantity | 4000 |
| Family Name | KK 254 |
| Fastening Type | Friction Lock |
| Features | - |
| Housing Material | Nylon |
| Ingress Protection | - |
| Insulation Color | Natural |
| Insulation Height | 0.228" (5.80mm) |
| Insulation Material | Polyamide (PA66), Nylon. |
| Lock to Mating Part | Yes |
| Manufacturer | Molex |
| Manufacturer Part No. | 22-05-7028 |
| Manufacturer Product Nu. | 0022057028 |
| Manufacturer Standard L. | 19 Weeks |
| Mated Stacking Heights | - |
| Material - Metal | Brass |
| Material - Plating Mati. | Tin |
| Material - Plating Term. | Tin |
| Material - Resin | Nylon |
| Material Flammability R. | UL94 V-0 |
| Mfr | Molex |
| Mounting Angle | Solder, Right |
| Mounting Type | Through Hole, Right Ang. |
| Number of Circuits | 2 |
| Number of Contacts | 2 |
| Number of Positions | 2 |
| Number of Positions Loa. | All |
| Number of Rows | 1, Through Hole |
| Operating Temperature | - |
| Orientation | Right Angle |
| Overall Contact Length | - |
| Package | Bulk |
| Packaging | Bulk, Bag |
| Part # Aliases | 0022057028 A-7395-2B |
| PC Tail Length | 3.80mm |
| PCB Thickness - Recomme. | 1.60mm |
| Pitch | 2.54 mm, 2, 2.54 mm (0.. |
| Pitch - Mating | 0.100" (2.54mm) |
| Pitch - Mating Interface | 2.54mm |
| Pitch - Termination Int. | 2.54mm |
| Plating Material | Tin |
| Plating min - Mating | 5.080?m |
| Plating min - Terminati. | 5.080?m |
| Polarized to Mating Part | Yes |
| Primary Type | Board Mount |
| Process Temperature max. | 235 |
| Product Category | Headers & Wire Housings |
| Product Status | Active |
| Product Type | Headers |
| RoHS | Headers |
| Row Spacing - Mating | - |
| Series | 7395 Series, KK254, 739. |
| Shrouding | Shrouded - 1 Wall |
| Special Features | Low-Halogen |
| Style | Board to Board or Cable |
| Termination | Solder, Through Hole |
| Termination Interface: . | Through Hole |
| Termination Style | Through Hole |
| Tradename | KK |
| Type | Right Angle Header, 739. |
| UL | E29179 |
| Voltage Rating | 250 V, - |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
 | TME | MX-7395-02B | 0.167 | 5 | 17171 | | MOLEX | | 0.167 @ 50 |
| Waldom | MOLEX 22-05-7028 | 0.37 | 150 | 23843 | | MOLEX | | 0.37 @ 150 |
| Onlinecomponents.com | 22-05-7028 | 0.422 | 1 | 7018 | | MOLEX / WALDOM | | 0.422 @ 50 |
| Power and Signal Group | 0022057028 | 0.4428 | 24000 | 50 | | Molex | | 0.4428 @ 24000 |
 | jensentools.com | 10158728 | 0.52 | 1 | 22773 | | Molex | | 0.52 @ 50 |
 | NEP Electronics | 22-05-7028 | 0.5441 | 150 | 22773 | | Molex | | 0.5441 @ 150 |
| Newark | 26AC6529 | 0.618 | 17100 | 50 | | MOLEX | | 0.618 @ 17100 |
| us.rs-online.com | 70091186 | 0.66912 | 1 | 50 | | Molex Incorporated | | 0.66912 @ 50 |
 | IBS Electronics | 22-05-7028 | 0.74 | 1 | 50 | | Molex | | 0.74 @ 50 |
 | Digi-Key | 2405467 | 0.786 | 1 | 24983 | | Molex | | 0.786 @ 50 |
| RS Delivers | 173-2916 | 0.9732 | 1 | 4620 | | Molex | | 0.9732 @ 50 |
 | swatee.com | 22-05-7028 | 1.35 | 1 | 1150 | | Molex | | 1.35 @ 50 |
| AmazonTP | B07QSYX312 | 59.58 | 1 | 50 | 1 | Molex / Waldom | | 59.58 @ 50 |
 | Zoro | G7767329 | 136.5 | 150 | 50 | | Molex | | 136.5 @ 150 |
