General Cable C5775.31.02

B01N8TO2UA

General Cable C5775.31.02 Coaxial Cable, RG 6/U Type, 1C/18 RG6/U Fl+60 PCT AL CL2/Cm, 1000' Pull-Pac, White

General Cable C5775.31.02 Coaxial Cable, RG 6/U Type, 1C/18 RG6/U Fl+60 PCT AL CL2/Cm, 1000zoom

Attributes

Key Value
ApprovalsNEC
Bonded Amount100 %, 60 %
Cable GroupRG-6
Cable TypeCoaxial
CategoryCables, Wires
CommentsNEC 800 CM, NEC 725 CL2.
Conductor MaterialSteel, Copper Coated
Conductor StrandSolid
Conductor TypeSolid Copper-Plated Ste.
Dielectric Diameter0.177" (4.50mm)
Dielectric MaterialCellular (Foam) Polyeth.
Family SeriesGeneral Cable Wire & Ca.
Features-
Gross Weight0 lbs
Impedance75 Ohms
Insulation MaterialFoam Polyethylene
Insulation Thickness0.18 "
Item NumberC5775.31.02
Jacket (Insulation) Dia.0.263" (6.68mm)
Jacket (Insulation) Mat.Poly-Vinyl Chloride (PV.
Jacket ColorWhite
Length1000.0' (304.80m)
ManufacturerGeneral Cable
Manufacturer Part NumberC5775
MfrGeneral Cable/Carol Bra.
Net Weight0 lbs
Nominal Attenuation1 MHz 0.26 dB/100 ft
Nominal Capacitance C-C16.20 pF/ft
Nominal Impedance75 Ohm
Nominal Outer Diameter0.275 "
Operating Temperature-
PackageSpool
Part StatusActive
Product SeriesRG 6U Type
RoHS CompliantNo
Series-
Shield Coverage100%, 60%
Shield MaterialFlexfoil?, Aluminum
Shield TypeFoil, Braid
ShieldingAluminum Braid and Foil.
UsageCATV
Velocity of Propagation83 %
VoP, Velocity of Propag.85
Wire Gauge18 AWG (0.82mm?)
Wire Gauge (AWG)18 AWG

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomGalcoC5775.31.02-GNCC0.131769General Cable0.13 @ 1
kirbyrisk.com22346600.143381000769General Cable0.14338 @ 1000
thumbzoomCarlton Bates Company0794072726390.01769GENERAL CABLE90.0 @ 1
thumbzoomDigi-KeyC5775W-31-1000-ND95.931769General Cable/Carol Brand95.93 @ 1
