1945106

mpn1945106
brandname: PHOENIX CONTACT
manufacturername: PHOENIX CONTACT

Pluggable Terminal Blocks 3P 3.5mm PIN STRIP

Pluggable Terminal Blocks 3P 3.5mm PIN STRIP

zoom

PartNumber: 1945106
PackageQuantity: 1
Manufacturer: Phoenix Contact
Label: Phoenix Contact

Attributes

Key	Value
Alternate Mfr Part Numb.	PST 1 0/ 3-3 5
Approvals	UL Recognized ; cUL Rec.
Category	Connectors, Interconnec.
Color	Black
Contact Material	-
Contact Mating Finish	Tin
Contact Tail Length	0.150" (3.81mm)
Current - IEC	8A
Current - UL	10 A
Current Rating	8 A
Description	TERM BLOCK HDR 3POS VER.
Detailed Description	3 Position Terminal Blo.
Diameter, Hole	1.1 mm
Digi-Key Part Number	277-1750-ND
Dimensions	13mm L, 13 L mm
Dimensions, Pin	1 mm
Family Name	COMBI Plug Family
Features	-
Header Orientation	Vertical
Hole Diameter	1.1 mm
Housing Material	Polyamide (PA), Nylon
Ingress Protection	-
Insulation Height	0.512" (13.00mm)
Insulation Material	PA
Manufacturer	Phoenix Contact
Manufacturer Product Nu.	1945106
Manufacturer Standard L.	16 Weeks
Material Flammability R.	UL94 V-0
Material, Insulation	PA
Mfr	Phoenix Contact
Mounting Type	Through Hole
Number of Contacts	3
Number of Levels	1
Number of Positions	3
Operating Force	PA
Operating Temperature	-
Package	Bulk
Pin Dimensions	1 mm
Pitch	0.138" (3.50mm), 3.5 mm
Plug Wire Entry	-
Positions Per Level	3
Primary Type	PCB Mount, Wire to Board
Product Status	Active
Screw Size	-
Series	COMBICON PST, COMBICON .
Surge Voltage	2.5 kV
Termination Style	Solder
Torque - Screw	-
Type	Header, Male Pins, Unsh.
UPC Code	4017918883270
Voltage - IEC	250 V
Voltage - UL	300 V
Voltage Rating	250 V
Voltage, Surge	2.5 kV
Wire Gauge or Range - A.	-
Wire Gauge or Range - m.	-
Wire Size	20 AWG
Wire Strip Length	-

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	Newark	69R9969	0.062	1	4		PHOENIX CONTACT		0.062 @ 1
	TTI	1945106	0.203	100	492		Phoenix Contact		0.203 @ 100
	Hotenda	H1540043	0.21	1	492		Phoenix Contact		0.21 @ 1
	industrialautomationparts.com	AE-008394	0.23	1	434		Phoenix Contact		0.23 @ 1
	Onlinecomponents.com	1945106	0.235	1	38		Phoenix Contact		0.235 @ 1
	Mouser	651-1945106	0.24	1	7631		Phoenix Contact		0.24 @ 1
	Airline Hydraulics	PHOENIX 1945106	0.28	1	357		Phoenix Contact		0.28 @ 1
	MRO Stop	753020486	0.32	1	312		Phoenix Contact		0.32 @ 1
	us.rs-online.com	70054940	0.32377	50	357		Phoenix Contact		0.32377 @ 50
	Digi-Key	950878	0.34	1	16602		Phoenix Contact		0.34 @ 1
	RS Delivers	548-7216	0.414	1	357		Phoenix Contact		0.414 @ 1
