- mpn056T17F15640
- brandname: MARATHON MOTORS
- manufacturername: MARATHON MOTORS
Marathon Motors 2 HP General Purpose Motor,3-Phase,1725 Nameplate RPM,Voltage 230/460,Frame 56HC
- Brand: CAI - MARATHON MOTORS
- PartNumber: 056T17F15640
- PackageQuantity: 1
- Manufacturer: CAI - MARATHON MOTORS
- Label: CAI - MARATHON MOTORS
Attributes
| Key | Value |
|---|
| Application | Application |
| Approval | Approval |
| Brand | Marathon Motors |
| Classification | General Purpose |
| Composition | Rolled Steel |
| Constant Torque Speed R. | Constant Torque Speed R. |
| Construction | Rolled Steel |
| Current Stock | 9 |
| Drive End Flange Type | C-Face |
| Efficiency | Efficiency |
| Efficiency % | 86.5 % |
| Enclosure | TEFC, Totally Enclosed . |
| Family Series | Marathon Electric Motors |
| FL Amps | 6.0/3.0 |
| FL Efficiency | 86.5 |
| Frame | 56HC |
| Frame Material | Frame Material |
| Frame Remarks | C Face, Removable Base |
| Frequency Rating | Frequency Rating |
| Gross Weight | 0 lbs |
| Hertz | 50, 60 |
| Horsepower | 2 hp |
| HP | 2 |
| Insulation Class | Insulation Class |
| International Shipping | No |
| Item | General Purpose Motor |
| Item Condition | Factory New |
| Item Number | 056T17F15640 |
| Kilowatts | 1.5 kW |
| KW | 1.5 |
| Length Less Shaft | 13 1/4 in |
| Manufacturer | Marathon Electric, Mara. |
| Manufacturer Part Number | G585A |
| Manufacturers Warranty . | 1 yr |
| Motor Application | General Application |
| Motor Design | 3-Phase |
| Motor Enclosure Design | Totally Enclosed Fan-Co. |
| Motor FLA | Motor FLA |
| Motor Frame Material | Steel |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Face/Base |
| Motor Service Factor | 1.15 |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | None |
| Mounting | Bolt-on Base |
| Mounting Type | Bolt-on Base |
| Mpn | 056T17F15640 |
| Nameplate RPM | 1,725 |
| NEMA Frame | 56HC |
| Net Weight | 48 lbs |
| Nominal Voltage | 240 VAC, 277 VAC, 347 V. |
| Number of Speeds | 1, Number of Speeds |
| Overall Length | 15 1/8 in |
| Part Number | 056T17F15640 |
| Phase | 3 |
| Product Type | General Purpose |
| RPM | 1800, 1,725 RPM |
| RPM Group | 1701-1800 |
| RPM Range | 1,701-1,800 |
| Service Factor | Service Factor, 1.15 |
| Shaft Dia. | 5/8 in |
| Shaft Length | 1 7/8 in |
| SKU | ZO-G8497837 |
| Speed (RPM) | 1725 |
| Speeds | Speeds |
| Standards | CE, CSA, UL Recognized |
| SubCategory | Motors/Ac Motors |
| Unspsc | Unspsc |
| Variable Torque Speed R. | Variable Torque Speed R. |
| Voltage | 230V, 460V, 230/460V AC |
| Voltage (AC) | 230 VAC, 460 VAC |
| Voltage Compatibility | 200-230/440V AC, 200-23. |
| Volts | 230/460 |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
 | Galco | 056T17F15640-MARA | 544.28 | 1 | In Stock | | Marathon Electric | 48.0 | 544.28 @ 1 |
 | Zoro | G8497837 | 571.99 | 1 | 1 | | Marathon Motors | 48.4 | 571.99 @ 1 |
 | motorsandcontrol.com | G585A | 608.3 | 1 | In Stock | | Marathon Motors | | 608.3 @ 1 |
 | Dealers Electric | 056T17F15640 | 640.52 | 1 | In Stock | | Marathon Electric | 40.0 | 640.52 @ 1 |
 | mecampbell.com | 056T17F15640 | 649.17 | 1 | In Stock | 33 | Marathon Motors | | 649.17 @ 1 |
 | sustainablesupply.com | C2792272 | 659.05 | 1 | In Stock | | Marathon | 48.0 | 659.05 @ 1 |
 | simsupply.com | ZO-G8497837 | 663.57 | 1 | In Stock | | Marathon Motors | | 663.57 @ 1 |
 | Raptor Supplies | AJ2KVE | 793.0168155 | 1 | In Stock | | MARATHON MOTORS | | 793.0168155 @ 1 |
 | pumpproducts.com | 056T17F15640 | 954.4 | 1 | In Stock | | Marathon | | 954.4 @ 1 |
